CLEANER MAINTENANCE

Replacing The Dust Bag

If the bag check indicator is red please check and, if necessary, replace the bag.
1.  Lift the bag door release latch

[13]

 to open the cover, pull the bag holder

[14]

 and pull the

bag collar to remove the bag

[15]

.

2.  Apply the peel and seal sticker, located on the bag collar, to the bag inlet. The full dust bag

should be disposed of correctly and carefully.

3.  Fold a new bag as shown on the bag and fit by inserting the collar into the bag holder.

4.  Refit the bag holder and close the bag door.

Warning - The bag door will NOT close if the dust bag and/or the bag holder are not assembled

to the cleaner. Always ensure the bag and bag holder are present when closing the bag door.
Remember: The bag check indicator may also be red if an obstruction has occurred. In this case

refer to ‘Removing A Blockage From the System’.

Cleaning the Filters

To maintain optimum performance of your cleaner, please wash the filters after each 5 bag

changes.

Cleaning the pre-motor filter:

1.  Lift the bag door release latch

[13]

 to open the cover and remove the bag holder.

2.  To remove the pre-motor filter slide the pre-motor filter frame from the cleaner.

[16]

3.  Remove the filter from the holder.

 [17]

4.  Wash it in hand warm water,

[20]

 and allow it to dry thoroughly before replacing to the

cleaner

[21]

.

Cleaning the exhaust filter:

1.  To remove the exhaust filter, unclip the exhaust filter cover

[18]

 and remove the filter pack.

[19

]

2.  Wash the filter in hand warm water

[20]

 and allow it to dry thoroughly before replacing to

the cleaner.

[21]

.

Remember: Do not use hot water or detergents. In the unlikely event of the filters becoming

damaged, fit a Genuine Candy replacement. Do not try and use the product without a dust bag

or filter fitted.

Cleaning the permanent cloth dust bag*

To maintain optimum performance we recommend that you wash the permanent cloth dust

bag under hand warm water after every 5 full bags. Remove excess water and leave to dry fully

before replacing.

ACCESSORIES AND NOZZLES

*

Certain models only

**Nozzle design may vary according to model

2

Removing a Blockage From The System

If the bag check indicator is illuminated or flashing:

1.  Check if the bag is full. If so refer to ‘Replacing The Dust Bag’.

2.  If it is not full, then;

A.  Do the filters need cleaning? If so refer to ‘Cleaning the Filter’.

B.  Check if there is any other blockage in the system - Use a rod or a pole to remove any

blockage from the Teletube or flexible hose.

Warning - The bag check indicator will turn red if the cleaner is used when full, if there is a

blockage or if the filters are dirty. If the cleaner is used for a significant period of time with the

bag check indicator is red, a thermal cut out will switch the cleaner off to prevent overheating.

The bag check indicator turn green once the cleaner has switched off to signal that the thermal

cut out has been activated. If this should happen, switch the cleaner off, unplug and correct the

fault. It will take about 30 minutes for the cut out to automatically reset.

All accessories can be fitted to the end of the handle or the end of the tube.

[23]

2 in 1 tool

 – Combines two functions in one, the 2 in 1 tool can be connected as a crevice tool.

By rotating the end piece converts to a dusting brush. The 2 in 1 tool can be stored neatly at

the rear of the cleaner.

[22]

Crevice Tool

 – For corners and hard to reach areas.

Dusting Brush

– For bookshelves, frames, keyboards and other delicate areas. To extend the

brushes push the button on the body of the tool.

Pet Hair Remover Mini Turbo Nozzle*

 – Use the mini turbo nozzle on stairs or for deep

cleaning on textile surfaces and other hard to clean areas

[1T]

.

Allergen Remover Mini Turbo Nozzle* –

Use the mini turbo nozzle on stairs or for deep

cleaning on textile surfaces and other hard to clean areas.

[1U]

Grand Turbo Nozzle*

 – Use the turbo nozzle for deep cleaning on carpets.

[1V]

Hard Floor Caresse Nozzle

*– For wooden floors and other delicate floors.

[1W]

IMPORTANT:

Do not use the grand turbo nozzle or mini turbo nozzles on rugs with long

fringes, animal hides and carpet pile deeper than 15mm. Do not keep the nozzle stationary

while the brush is rotating.

GB
