14

en

Replacing the micro active carbon filter

Figure

Unlatch the twin cylinders and open them
forwards. (See fig. 20)

Unlatch the dust container and remove it from
the appliance (see fig. 21)

Open the exhaust filter cover as far as possi-
ble in the direction of the arrow. The cover
engages in this position. (See fig. 24)

Remove and dispose of the micro active
carbon filter.

Fit a new filter (BBZ192MAF )

Close the exhaust filter cover.
Insert the dust container into the appliance
until it engages (you will hear a positive click).
Push the twin cylinders back into position
(effectively closing the vacuum cleaner),
making sure that they engage (you will here a
positive click). (See fig. 23)

Replacing the HEPA filter

Figure

Unlatch the twin cylinders and open them
forwards. (See fig. 20)

Unlatch the dust container and remove it
from the appliance (see fig. 21).

Open the exhaust filter cover as far as
possible in the direction of the arrow. The
cover engages in this position (see fig. 24).

Remove and dispose of the HEPA filter.

Fit a new filter (BBZ153HFB ).

Close the exhaust filter cover.
Insert the dust container into the appliance
until it engages (you will hear a positive click).
Push the twin cylinders back into position
(effectively closing the vacuum cleaner),
making sure that they engage (you will here
a positive click) (see fig. 23).

Cleaning the twin cylinders

Figure

Use the release button (1) to unlatch the twin
cylinders and open them forwards (see fig. 20).

Turn the cylinder cover as shown to remove
from the appliance.

Clean the cylinder and cover.

29

28

27

Figure

Replace the cylinder cover and lock it into
place by turning in the direction of the arrow
(please make sure that you replace the one
marked with an "L" on the left hand side and
the one marked with an "R" on the right hand
side).

Push the twin cylinders back into position
(effectively closing the vacuum cleaner),
making sure that they engage (you will here a
positive click) (see fig. 23).

!

Attention: The inside of the twin cylinders

may become scratched with use and start
to look opaque.This does not, however,
affect the performance of the vacuum
cleaner in any way, i.e. it will continue to
function as normal.

Care

Always switch off the vacuum cleaner and dis-
connect the power cord from the mains before
cleaning the appliance. The vacuum cleaner and
plastic accessories can be cleaned with a com-
mercial plastic cleaner.

!

Do not use a scourer, glass-cleaning agent
or all-purpose cleaning product. Never
immerse the vacuum cleaner in water.

The dust compartment can, if necessary, be
cleaned with a second vacuum cleaner or simply
wiped with a dry cloth or dusting brush.

Subject to technical modifications.
