Suction

Illustration 9

Setting the floor nozzle:

fitted carpets and carpets

smooth floors

Caution!

Floor tools are subject to a certain amount of wear,
depending on the type of hard floors you have
(e.g. rough, rustic tiles). Therefore, you must check
the underside of the floor tool at regular intervals.
Worn undersides of floor tools may have sharp edges
that can damage sensitive hard floors, such as parquet
or linoleum. The manufacturer does not accept any
responsibility for damage caused by worn floor tools.

Illustration 10*

Vacuuming with accessories
(insert the grip or the suction pipe, depending on
requirements).

a)

Corner nozzle
To vacuum in corners and joins.

b)

Upholstery nozzle
To vacuum upholstered furniture, curtains,
mattresses etc..

c)

Furniture brush
To vacuum window frames, cupboards, sections etc..

Illustration 11

When taking brief vacuuming pauses, you can use the
parking aid on the back of the appliance. Push the
hook on the floor nozzle in to the recess on the back
of the appliance.

Illustrations 12 + 13

When vacuuming, e.g. stairs, the appliance  can also
be carried using the two grips.

After work

Illustration 14

Pull out the mains plug.
Pull briefly on the mains cable and then let  go (the
cable rolls up automatically).

Illustration 15

To store / transport the appliance, you can use the
storing aid on the underside of the appliance. Stand
the appliance up straight. Push the hook on the floor
nozzle in to the recess on the underside of the
appliance.

Changing the filter

Replace the dust bag

Illustration 16

The filter change display on the lid turns yellow.

Illustration 17 + 18

Open the lid and take it off by moving the locking
lever in the direction of the arrow.

83

C TURBO-UNIVERSAL

®

-upholstery brush

BBZ42TB
Simultaneously brush and vacuum upholste-
red furniture, mattresses, car seats, etc..
Particularly suitable for vacuuming animal  hair and
fur. The brush roller is driven by the suction orce of
the vacuum cleaner.
No electrical connection required.

D TURBO-UNIVERSAL

®

- floor brush

BBZ102TBB

Simultaneously brush and vacuum shortpile carpets
and fitted carpets or any kind of covers. Particularly
suitable for vacuuming animal hair and fur. The
brush roller is driven by the suction force of the
vacuum cleaner.
No electrical connection required.

E Hard floor nozzle

BBZ123HD

To vacuum smooth flooring
(parquet, tiles, terracotta...).

Before using for the first time

Illustration 1*

Push the handle onto the flexible tube and until it
engages.

Starting up

Illustration 2
a)

Position the suction hose with the direction arrow
pointing upwards - lock in to the suction opening.

b)

When removing the suction hose, press together
both latches and pull out the hose.

Illustration 3

Fit together the grip and the suction pipe.

Illustration 4

Fit together the floor nozzle and the  suction pipe.

Illustration 5*
a)

Fit together the suction pipe.

b)

by moving the adjusting head to the direction of the
arrow, releasing the telescopic pipe and setting to
the required length.

Illustration 6

Take the mains cable by the plug and pull out the
desired length and then plug in to the mains socket.

Illustration 7

Switch on / off the vacuum cleaner by pressing the
on / off button in the direction of the arrow.

Illustration 8

Set the level of suction by turning the on / off button
in the direction of the arrow.
