Illustration 6

The lower cover can be removed for cleaning the fan and
the fan chamber.

a)

Closed chamber.
To remove the cover act to the two little side wings
pushing them toward you, lift up with a light rotation.

b)

Open chamber

c)

Insert the front lips to reassembly the lower cover

d)

Push the cover up to click.

!

Please observe!

Never operate the turbo brush without the lower cover or
with the lower cover not well locked.

Subject to technical change without notice.

en

Please fold out the picture page!

Starting up

Illustration 1
a)

Fit the turbo brush onto the suction pipe.

b)

Push the telescopic pipe into the supports of the turbo
brush until it audibly engages. Press the unlocking
sleeve and pull out the telescopic pipe to remove it.
(Equipment will vary with each model).

Vacuuming with the brush

!

Please observe!

Only vacuum using the brush on full suction power, i.e.
max. performance of the vacuum cleaner.

Illustration 2

The turbo brush has the possibility to change the rotation
speed of the brush from a maximum »A« to a complete
stop »B«

Moving the slider a little from »A« to »B« permits an
optimum cleaning effect for the different floor coverings
(long or short pile carpets).
Closing completely the fan inlet (position »B«)it is
possible to use the device as a normal floor nozzle.

Illustration 3

Only brush the fringes in the direction of the arrow.

Maintenance

Always switch off the vacuum cleaner and pull out the plug
before performing any maintenance work. Remove the
turbo brush from the suction / telescopic pipe.

Illustration 4

Cut off any wrapped around hair or threads using a pair
of scissors.

Illustration 5

Then vacuum up the threads and hair using the corner
nozzle.
