Please note

The mains socket must be protected by at least a 16
amp fuse.
If a fuse should blow when you switch on the appliance,
this may be because other electrical appliances which
have a high current draw are connected to the same
power circuit.
To prevent the fuse from blowing, select the lowest
power setting before switching the appliance on, and
increase the power only once it
is running.

Fold out picture pages.

Before using for the first time

Figure

Push the handle onto the flexible tube and until it engages.

Figure

Push the crevice nozzle and upholstery nozzle back into the
accessories holder as indicated.

Setting up

Figure
a)

Push the flexible hose adapter into the air intake opening on
the vacuum cleaner lid until it engages.

b)

To remove the flexible hose, press the two lugs together and
pull the tube out.

Figure
a)

Push the handle into the suction pipe/telescopic tube.
To remove it, turn the handle slightly and pull it off the tube.

b)

Push the handle straight into the telescopic tube until it
engages.
To release the connection, squeeze the collar sleeve and
pull the handle out.

Figure
a)

Connect the floor tool and the telescopic tube together.

b)

Push the telescopic tube straight into the
connecting piece of the floor tool until it engages.
To release the connection, squeeze the locking collar and
pull the telescopic tube out.

Figure
a)

Connect the suction pipes together, or

b)

Unlock the telescopic tube to adjust its length by moving
the sliding switch in the direction of the arrow.

Figure

Holding the power cord by the plug, pull out the required
length and plug it into the mains socket.

7

6*

5*

4*

3

2*

1*

Figure

Press the on/off button in the direction of the arrow to
switch your vacuum cleaner on/off.

Figure

Adjust the suction by turning the on/off button in the
direction of the arrow.

Vacuuming

Figure

Adjusting the floor tool:

Rugs and carpets

=>

Hard surfaces

=>

Figure

Adjust the "autofloor" floor tool:

Hard floor setting

=>

Fixed position for vacuuming hard
floors/ parquet

Automatic setting

=>

auto

The nozzle adjusts automatically to the floor covering and
switches from hard floors / parquet
to carpeted floors

Carpet setting

=>

Fixed position for vacuuming rugs and
carpets

If you are vacuuming varying types of floor coverings (hard
floors <-> carpets), we recommend that you use the
automatic setting so that the nozzle adjusts automatically
to the floor and you do not need to switch over the nozzle
setting.

Figure

Remove the upholstery nozzle and crevice nozzle from the
accessories holder as illustrated.

Figure

Vacuuming with accessories
Attach the nozzles to the suction pipe or handle as required:

a)

Crevice nozzle for vacuuming crevices and corners, etc.

b)

Upholstery nozzle for vacuuming upholstered furniture,
curtains, etc.

c)

Hard furnishings brush
For cleaning window frames, cabinets, mouldings, etc.

d)

Hard-floor brush
For vacuuming hard floor coverings (tiles, parquet flooring,
etc.)

Figure

After use, push the crevice nozzle and upholstery nozzle
back into the accessories holder as indicated.

Turbo brush

If your vacuum cleaner is equipped with a turbo brush, please
consult the accompanying instruction manual for notes on use
and maintenance.

14

13*

12

11*

10

9

8

*Depending on equipment
