39

c)

Hard furnishings brush
For window frames, cabinets, profiles, etc.

䡲

Fold up the upholstery nozzle in the direction of the
arrow.

䡲

The brush ring is extended by turning in the direc-
tion of the arrow.

䡲

The brush ring must be turned back in and the
upholstery nozzle folded back up before the combi-
nation tool is inserted into the accessory holder.

Figure

Mattress nozzle
For vacuuming mattresses, upholstery etc.
(attach to handle or suction pipe as required).

Figure

Pet hair upholstery nozzle

䡲

For easy and thorough removal of pet hair (attach to
handle or suction pipe as required).

䡲

To clean the pet hair upholstery nozzle, simply vacuum
using the handle.

䡲

If it is very dirty, the pet hair upholstery nozzle can also
be opened.
To do this, turn the two screws on the sides of the nozzle
(e.g. using a coin) and remove the inner part from the
nozzle.

䡲

After cleaning, replace the inner part (make sure it is
correctly seated) and screw to the housing.

Figure

Pet hair tool
Floor tool for easy and thorough vacuuming of pet hair.
Push the telescopic tube into the connecting piece of the
pet hair tool until it engages.
Press on the locking collar and pull out the telescopic
tube to disconnect.
To clean, simply vacuum the tool using the suction
pipe/handle.

Figure

Hard-floor brush

For vacuuming hard floor coverings (tiles, parquet floor-
ing, etc.)
Push the telescopic tube into the connecting piece of
the hard-floor brush until it engages.
Press on the unlatching sleeve and pull out the telescop-
ic tube to disconnect.

Figure

You can use the parking aid on the back of the vacuum
cleaner if you wish to stop vacuuming for a short time.
Slide the plastic lug on the tool connector into the
groove at the back of the vacuum cleaner.

15

14*

13*

12*

11*

When the work is done

Figure

䡲

Switch the vacuum cleaner off and unplug the power
cord from the mains.

䡲

Tug the power cord and let go. The cable then rewinds
automatically.

䡲

To reactivate or deactivate the cable brake, quickly tug
the power cord.

Figure

To store or transport the vacuum cleaner, use the stor-
age aid on the underside of the vacuum cleaner. Stand
the vacuum cleaner up on its end. Slide the plastic lug
on the floor tool into the groove on the underside of the
unit.

Changing the dust bag and filters

Replacing the dust bag

Figure

䡲

If the dust bag change indicator lights up brightly and
evenly when the floor tool is lifted from the carpet and
the highest suction power is selected, the dust bag must
be changed, even though it may not yet be full. In this
case it is essential to change the dust bag due to the
type of material it contains.

䡲

Open the dust bag compartment lid by moving the dust
compartment locking lever in the direction of the arrow.

Figure

Seal the dust bag by pulling the self-seal tap and then
remove it.

Figure

Insert a new dust bag into the holder and close the dust
bag compartment lid.

!

Caution: the dust bag compartment lid will only close
when the disposable or textile filter are inserted.

If the dust bag change indicator is still lit after the
dust bag has been changed, please check whether
the nozzle, tube or flexible hose are blocked.

Cleaning the motor protection filter

The motor protection filter should be cleaned regularly by
knocking out the dirt and rinsing.

Figure

䡲

Open the dust bag compartment lid (see Figure 18).

䡲

Pull out the motor protection filter in the direction of the
arrow.

䡲

Clean the motor protection filter by tapping it.

䡲

If it is very dirty, the motor protection filter should be
rinsed.
The filter must then be left to dry for at least 24 hours.

21

20

19

18

17

16
