11
en
Fold out picture pages.
Before using for the first time
Figure
Push the handle onto the flexible hose until it engages.
Setting up
Figure
a)
Push the flexible hose adapter into the opening on the
vacuum cleaner until it engages.
b
To remove the flexible hose, press the release button and
pull the hose out.
Figure
a)
Connect the handle and the telescopic tube together.
b)
Push the handle into the telescopic tube until it engages.
To release the connection, squeeze the locking collar and
pull the telescopic tube out.
Figure
a)
Connect the floor tool and the telescopic tube together.
b)
Push the telescopic tube straight into the
connecting piece of the floor tool until it
engages.
To release the connection, squeeze the locking collar
and pull the telescopic tube out.
Figure
To adjust the length of the telescopic tube, adjust the
adjusting sleeve/sliding switch in the direction of the
arrow and adjust the tube to the required length.
Figure
Take the mains plug, pull the mains cable to the required
length and insert the plug into a socket.
Figure
a)
Press the ON/OFF button in the direction of the arrow to
switch your vacuum cleaner on.
b)
The button can also be applied using the swing handle.
Vacuuming
Figure
The required suction power can be selected infinitely
variably by adjusting the slide control.
䡲
Lowest
suction range:
For vacuuming delicate fabrics, e.g. curtains.
8
7
6
5*
4*
3*
2
1*
䡲
Low
suction range:
For daily vacuuming of lightly soiled floors.
䡲
Medium
suction range:
For vacuuming durable floor coverings, hard floors and
for heavily soiled surfaces.
䡲
High
suction range:
For vacuuming stubborn dirt and very heavily soiled
surfaces.
Figure
Adjusting the floor tool:
a)
For vacuuming rugs
and carpets
=>
b
For vacuuming
hard floors
=>
Figure
Adjust the autofloor floor tool:
䡲
Hard floor setting
=>
Fixed position for vacuuming hard/parquet floors
䡲
Automatic setting
=>
auto
The floor tool adjusts automatically to the floor
covering and switches from hard/parquet floors to
carpeted floors
䡲
Carpet setting
=>
Fixed position for vacuuming rugs
and carpets
If you are vacuuming varying types of floor coverings
(hard floors <-> carpets), we recommend that you use
the automatic setting so that the nozzle adjusts
automatically to the floor and you do not need to switch
over the nozzle setting.
Figure
To clean, switch the autofloor tool to the hard floor
setting and simply vacuum using the suction
pipe/telescopic tube.
Turbo brush
If your vacuum cleaner is equipped with a turbo brush,
please consult the accompanying instruction manual for
notes on its use and maintenance.
Figure
Vacuuming with accessories
(attach to handle or suction pipe as required).
a)
Crevice nozzle
For cleaning crevices and corners.
b)
Upholstery nozzle
For cleaning upholstered furniture,
curtains, etc.
c)
Hard furnishings brush
For vacuuming picture frames, books, furniture requiring
particular care, etc.
Figure
Other accessories that you do not need can be stored
easily in the accessories compartment of the vacuum
cleaner lid.
13
12*
11*
10*
9
