33

Replacement parts and accessories

A

Replacement filter pack

Filter type G (BBZ41FG)
For best performance: Gplus (BBZ41GPLUS)

Contents:
4 filter bags with seal
1 micro-hygiene filter

http://

www.dust-bag-bosch.com

B Textile filter (long-term filter)

BBZ10TFG

Reusable filter with Velcro fastening.

C HEPA Filter

BBZ8SF1

additional filter for pure exhaust air.
Recommended for those with allergies.
Replace every year.

D TURBO-UNIVERSAL

®

-upholstery brush

BBZ42TB

Simultaneously brush and vacuum upholstered furniture,
mattresses, car seats, etc..
Particularly suitable for vacuuming animal hair and fur.
The brush roller is driven by the suction force of the
vacuum cleaner.
No electrical connection required.

E TURBO-UNIVERSAL

®

- floor brush

BBZ102TBB

Simultaneously brush and vacuum short-pile carpets
and fitted carpets or any kind of covers. Particularly
suitable for vacuuming animal hair and fur. The brush
roller is driven by the suction force of the vacuum
cleaner.
No electrical connection required.

F Hard floor nozzle

BBZ123HD

To vacuum smooth flooring (parquet, tiles, terracotta...).

Before using for the first time

Illustration 1*

Push the handle onto the flexible tube and until it
engages.

Starting up

Illustration 2
a)

Lock the suction hose supports into the suction opening.

b)

When removing the suction hose, press together both
latches and pull out the hose.

Illustration 3*

Connect the handle and the suction hose.

Illustration 4*
a)

Connect the floor nozzle and the suction hose.

b) Insert the telescopic pipe into the supports of the floor

nozzle and secure by turning.

Illustration 5*
a)

Connect the suction hoses.

b)

Unlock the telescopic pipe and adjust to the desired
length by moving the adjusting button / sliding sleeve in
the direction of the arrow.

Illustration 6*

Slide the attachment support on to the combination
nozzle and clip on to the suction / telescopic pipe

Illustration 7

Take the mains cable by the plug and pull out the desired
length and then plug in to the mains socket.

Illustration 8

Switch on / off the vacuum cleaner by pressing the on /
off button in the direction of the arrow.

Illustration 9*
a)

Set the level of suction by turning the on / off button in
the direction of the arrow.

b)

The suction performance can also be regulated by
turning the secondary air regulator in the direction of the
arrow.

Secondary air opening open

Suction reduced

Secondary air opening closed

Maximum suction

Suction

Illustration 10

Setting the floor nozzle:

fitted carpets and carpets

smooth floors

Caution!

Floor tools are subject to a certain amount of wear,
depending on the type of hard floors you have
(e.g. rough, rustic tiles). Therefore, you must check
the underside of the floor tool at regular intervals.
Worn undersides of floor tools may have sharp edges
that can damage sensitive hard floors, such as parquet
or linoleum. The manufacturer does not accept any
responsibility for damage caused by worn floor tools.

Illustration 11*

Vacuuming with accessories
(connect to the handle or the suction hose as required)

a)

Combination nozzle
For vacuuming in corners, joins, upholstery, curtains etc.

b)

Corner nozzle
For vacuuming in corners and joins

c)

Upholstery nozzle
For vacuuming upholstery, curtains etc.

d)

Mattress nozzle
For vacuuming mattresses, upholstery etc.

e)

Hard floor nozzle
For vacuuming hard floor surfaces (tiles, parquet etc.)

f)

Furniture brush
To vacuum window frames, cupboards, sections etc..
