26

De

s

cription of the appliance

1

Nozzle holder with accessory connection*

2

Nozzle holder without accessory connection*

3

Carpet button*

4

SelfClean button

5

Inspection window with turbine system

6

Brush roller release button

7

Brush roller guide rod

8

Brush roller

Starting up for the fir

s

t ti

m

e

Fig.

1*

a)

 Nozzle without accessor y connection:
Place the Turbo brush on the suction pipe. To re -
lease the connection, turn the pipe slightly and pull
it out of the Turbo brush holder.

b)

 Nozzle with accessor y connection:
Slide the telescopic pipe until it clicks into place
in the holder for the Turbo brush. To release the
connection, push the release collar and pull out the
telescopic pipe.

Vacuu

m

 bru

s

hing

!

Plea

s

e note:

   Only vacuum brush at full suction power, i.e. ma x.

power setting on the vacuum cleaner.

Cleaning carpet

s

/carpeted floor

s

When cleaning carpets, the brush roller star ts auto-
matically three seconds after the vacuum cleaner is
switched on.
When cleaning carpets, the turbine system works wi-
thout any braking. This creates the ma ximum suction
power for the nozzle.

Cleaning hard floor

s

The turbine system detects the type of flooring. When
changing from carpeted floors to hard floor, the tur-
bine system star ts to brake down the rotation speed
and therefore reduces the noise level.
If you change flooring from hard floor to carpet the
turbine system doesn’t brake anymore and have again
the ma ximum suction power.

Fig

2*

 Carpet button*

‡

Press the Carpet button when vacuuming long-pile
carpets.

This reduce a force of pushing nozzle and speed up
brush roller.

!

Plea

s

e note:

   The Carpet button can be pressed when cleaning

all types of flooring.

Fig.

3

 SelfClean button

‡

Press and hold the SeflClean button when nozzle
is on the hard floor to order to use the ma ximum
air flow and the minimum resistance for the brush
roller.

‡

The best results of cleaning brush roller are with
using function 3 times per 5 seconds. If it necessa-
r y please hold the button longer

!

Plea

s

e note:

   We recommend using the SelfClean function after

using the Turbo brush.

Maintenance

Before carr ying out any maintenance work, switch
off the vacuum cleaner and pull out the mains plug.
Remove the Turbo brush from the suction/telescopic
pipe.

Fig.

4

‡

Use the release button to release the brush roller
and pull it sideways out of the Turbo brush.

Fig.

5

‡

 Remove the dir t.

‡

When hairs gets stuck between the brush roller re-
lease button and the brush roller you can separate
them by pulling on the release button with some
force. Then you can clean the a xis and put the par ts
back together.

Fig.

6

‡

 Push the brush roller in sideways along the guide
rod and into the Turbo brush, and lock it in place
using the release button.

!

Caution:

   The Turbo brush must only be used with the brush

roller fitted.

Subject to technical modifications.

*depending on model

en
