45

Turbo-brush

The turbo brush vacuums and brushes carpets when
connected to the vacuum cleaner. It is particularly
suitable for removing dust, fluff, threads and hair. It
noticeably refreshes trodden down carpet pile. The
turbo brush can be used on hard flooring and carpets.

Figure
a)

Fit the turbo brush onto the suction pipe.

b)

Push the telescopic pipe into the supports of the
turbo brush until it audibly engages.

●

Press the unlocking sleeve and pull out the
telescopic pipe to remove it.(Equipment will vary
with each model)

!

Please observe!

Only vacuum using the brush on full suction power,
i.e. max. performance of the vacuum cleaner.

Figure

Vacuuming with the brush

●

If the turbo brush is vacuuming too strongly, i.e. the
slideforce is too high, you can change the slide force by
setting the suction power position, thus enabling an
optimum cleaning effect for the different floor coverings.
long pile carpets

=>

short pile carpets

=>

Figure

●

Only brush the fringes in the direction of the arrow.

Maintenance

Always switch off the vacuum cleaner and pull out the
plugbefore performing any maintenance work. Remove
theturbo brush from the suction / telescopic pipe.

Figure
a)

Cut off any wrapped around hair or threads using a
pair of scissors.

b)

Then vacuum up the threads and hair using the
corner nozzle.

Drill dust nozzle

Figure
a)

Secure the drill dust nozzle to the handle and then
place against the wall, so that the nozzle drill hole
opening sits directly over the hole to be drilled.

b)

Select the lowest power setting and then switch on
the vacuum cleaner.
Suction holds the drill dust nozzle in the required
position.

c)

Depending on the surface of the wall to be drilled it
may be necessary to readjust the power to a higher
setting to ensure the drill dust nozzle is firmly
attached.
Any fine particles are automatically vacuumed up.

Figure

You can use the parking aid on the back of the vacuum
cleaner if you wish to stop vacuuming for a short time.

●

Once you have switched off the appliance, slide the
hook on the floor tool into the recess on the rear of
the appliance.

16*

12*

13*

14*

15*

17

*depending on model

Figure

To overcome obstacles, e.g. steps, the appliance can
also be carried by the handle on the appliance body.

When the work is done

Figure
a)

Pull out the mains plug.

b)

Briefly pull on the power cord and then release it (the
power cord retracts automatically).

Figure

To store/transport the appliance, you can use the
storage aid on the underside of the appliance.

a)

Stand the appliance upright on its end.

b)

Slide the hook on the floor tool into the recess on the
underside of the appliance.

Changing the filter

!

Please note:

Always switch off the appliance before

changing the filter.

Cleaning the motor protection filter

The motor protection filter should be cleaned regularly
by knocking out the dirt and rinsing.

Figure

●

Open the dust bag compartment lid.

Figure

a)

Release the motor protection filter from the catch by
pulling it sideways, and pull it out in the direction of
the arrow.

b)

Clean the motor protection filter by tapping out the
dirt.

c)

If it is very dirty, the motor protection filter should be
rinsed.

●

The filter must then be left to dry for at least 24
hours.

d)

After cleaning, refit the motor protection filter into
the appliance, lock it in place and close the dust bag
compartment lid.

Replacing the dust bag

Figure
Appliances with filter replacement indicator:

●

If the filter replacement indicator in the lid is filled
completely when the floor tool is lifted from the floor
with the highest suction level selected, the dust bag
must be changed, even though it may not yet be full.
Even if the dust bag is not full, it may still need to be
changed due to the type of dust that has been
vacuumed. First check that the nozzle, suction pipe
and flexible hose are not blocked, as this would also
lead to the filter replacement indicator being
triggered.

●

The handle can easily be detached from the hose to
remove blockages.
