11

Storage conditions:

Products are stored in dry, ventilated warehouses at tem-

peratures from 0 ° C to +40 ° C with a relative humidity of

not more than 80% .

Transportation:

It is strongly perhebited dropping and any mechanical im-

pact on the pfckaging during transportation .
When unloading / loading, it is not allowed to use any

type of equipment that works on the principle of packing

clamping .

DESCRIPTION OF THE PRODUCT (Fig.2)

WARNING: To reduce the risk of fire, electrical

shock, or injury.
1.

 Do not use outdoors or on wet surfaces;

2.

 Do not allow to be used as a toy . Close attention is nec-

essary when used by or near children;

3.

Use only as described in this manual . Use only manu-

facturer’s recommended attachments;

4.

Do not use vacuum if it has been dropped, damaged,

left outdoors, or dropped in water . Return it to an author-

ized service center;

5.

 Do not handle plug or appliance with wet hands;

6.

 Do not put any object into openings . Do not use with

any opening blocked; keep free of dust, lint, hair and any-

thing that may reduce air flow;

7.

Keep hair, loose clothing, fingers, and all parts of body

away from openings and moving parts;

8.

 Do not pick up anything that is burning or smoking,

such as cigarettes, matches, or got ashes;

9.

Use extra care when cleaning on stairs;

10.

 Do not use to pick up flammable or combustible liq-

uids such as gasoline or use in areas where they may be

present;

11.

Look on your vacuum and follow all label and marking

instructions;

12.

 Keep end of hose, wands and other openings away

from your face and body;

13.

Do not use the vacuum cleaner without dust cup filter

in place;

14.

 Always unplug this appliance before connecting or

disconnecting vacuum hose;

15.

Store the vacuum indoors . Put the vacuum away after

us to prevent tripping accidents;

9.

Dust tank bottom re-

lease button;

10.

Transformation joint;

11.

Multi crevice nozzle;

12.

Charger;

13.

Sponge, HEPA.

1.

Brush;

2.

 Aluminum tube;

3.

 Tube release button;

4.

 Indicator light;

5.

Body release button;

6.

Power switch;

7.

Dust cup;

8.

Dust tank upper part

release button;

16.

 Use the incorrect battery will damage motor and us-

ers . Please use the recommended batteries;

17.

Use only on dry, indoor surfaces;

18.

Do not use for any purpose other than described in

this user’s guide;

19.

If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard .

PRECAUTIONARY MEASURES

If the opening that sucks in the air, the brush or exten-

sion tubes are blocked, you should switch off the vacuum

cleaner at once . First clear the blocked substance before

you attempt to start the vacuum cleaner again .

1.

Do not operate the vacuum cleaner too close to heaters

and like radiators, cigarette butts etc . (Fig . 3);

2.

Before you start using the vacuum  cleaner,please

remove large or sharp objects from the floor in order to

prevent that the filter is damaged . Do not use the vacuum

to clean anything that is easy to burning, such as gas and

cigarettes (Fig . 4) .

ASSEMBLING VACUUM CLEANER
1.

 Install the conversion connector (Fig . 5) .

When you need to be used directly to access the body

accessories, please use the conversion joint connection .

2.

 Install extended aluminum tube (Fig . 6) .

We can use aluminum tube longer a head of connection

machine (after heard cut when installation, the installa-

tion is successful), and then the other side of the connect

accessories in the pipe (right), so that it can be used as

vertical vacuum cleaner:
* Connection after shangdi brush can be directly used to

clean the floor or carpet .
* Connected to brush or flat after absorption, can be used

to clean the ceiling, curtain is difficult to clean at ordinary

times, such as higher place, very convenient and practical .

3.

Remove and install the dust cup .

Remove dust cup from body: push the release button of

dust cup . Then take out the dust cup from body (Fig . 7) .
Install dust cup on body: first make the underside of dust

cup to connect with the body . (pls pay attention to the

fitting position and direction) . Then push the dust cup  to

close with the body . The dust cup will be locked after a

voice of “kata” (Fig . 8) .

4.

 Installation and remove the battery pack .

•  Remove the battery pack: to promote the body BaoSuo

button at the bottom of the battery, and then along the

direction of mobile battery pack, so that you can remove

the battery pack from the body (Fig . 9) .
•  Install the battery pack: according to the direction

along the guide into the battery pack, heard a loud

“crack” the sound of the dust cup lock (Fig . 10) .

5.

Indicator light (Fig .11) .

•  In the work, the light of area A will be extinguished as

the quantity of electricity decreases, and the green light

of zone B will be always bright .
