12

14.

 Always unplug this appliance before connecting or

disconnecting vacuum hose;

15.

Store the vacuum indoors . Put the vacuum away after

use to prevent tripping accidents;

16.

 Use the incorrect battery will damage motor and us-

ers . Please use the recommended batteries;

17.

Use only on dry, indoor surfaces;

18.

Do not use for any purpose other than described in

this user’s guide;

19.

If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard .

PRECAUTIONARY MEASURES

If the opening that sucks in the air, the brush or exten-

sion tubes are blocked, you should switch off the vacuum

cleaner at once . First clear the blocked substance before

you attempt to start the vacuum cleaner again .

1.

Do not operate the vacuum cleaner too close to heaters

and like radiators, cigarette butts etc . (Fig . 3);

2.

Before you start using the vacuum  cleaner,please

remove large or sharp objects from the floor in order to

prevent that the filter is damaged . Do not use the vacuum

to clean anything that is easy to burning, such as gas and

cigarettes (Fig . 4) .

ASSEMBLING THE VACUUM CLEANER WITH AC-

CESSORIES
1.

 Install the floor brush head (Fig . 5):

The floor brush head is suitable for all floors .
Floor brush head connected directly to the vacuum

cleaner body unit until you hear a audible clicking

noise .
Floor brush head connected with the aluminum tube

until you hear a audible clicking noise .
Disassemble the floor brush head (Fig . 5):
Press the tube release button, then remove the alumi-

num tube and floor brush head .

2.

 Install the 2in1 crevice nozzle (Fig . 6):

The crevice nozzle is suitable for narrow gaps cleaning

and for using on upholstered surface cleaning .
Insert the 2 in 1 crevice nozzle into the connecting

joint, then insert the connecting joint to the vacuum

cleaner body unit .
The brush on the crevice nozzle can be pulled forwards

or backwards as need .

USE THE VACUUM CLEANER
1.

Install the battery pack (Fig . 7):

Slide the battery pack onto the body block until you

hear and feel it click into the place .

2.

Switch the vacuum cleaner on or off (Fig . 8):

To switch it on, press the power switch, button, the

vacuum cleaner is ON, and LED light is lighting up . If

you need the high suction for cleaning, press the high

mode button .
To switch it off, press the power switch button one

more .

CHARGE THE VACUUM CLEANER

The vacuum cleaner must be switched off for charging .
The rechargeable battery is not fully charged upon de-

livery . To reach the maximum charging capacity, charge

the appliance up fully before using it for the first time .
Charging the product (Fig . 9):
Plug the adapter plug into the connection socket on

the rear side of the vacuum cleaner .
The LED indicator light flashes one by one while it is

charging .
Once all the indicator light up, the battery is fully

charged .
Note:  If the wrong adapter, during the charging, all the

LED light will flash quickly, not one by one flashed while

charging .

CLEAN THE VACUUM CLEANER
1.

 Drop dust:

Push the dust cup bottom release button, then the dust

will fall down automatically . Usually you may only do

like this to drop the dust (Fig . 10)
Clean the dust cup . Press the dust cup release button,

then remove the dust cup from body .
Press the dust cup cover (for air exhaust) release but-

ton, take out the filter assembly out of the dust cup,

then you can clean them with soft brush or wash them

with water . You should dry them completely before you

use again (Fig . 11) .
Assemble the dust cup back after cleaning . Connect

the dust cup set to the body you hear a audible clicking

noise . The dust cup will be locked .(pleases pay atten-

tion to the fitting position and direction) .

2.

Clean the filter:

Take out the filter set (Fig . 12)
Clean the filter by soft brush or rinse it in  water and

dry them completely before use again . All the filters are

washable . (we recommend you to clean the filters when

feeling the suction power becoming weak .)
Note: The above filters should be equipped in correct

places when work the vacuum machine .

3.

Clean the floor brush head (Fig . 13):

Remove the floor brush head from the vacuum cleaner

by pressing the release button . Slide the locking button

slightly . Take out the brush roller by hand .
If necessary, carefully remove dirt/hair with a pair of

scissors .
If need be, the brush roller can be washed . Let it dry
