N EW     PRO D UC T    IN FO RM A TIO N

Sp e cif ica tio n s

Power supply:

AC : 100 V - 240 V, 50 Hz / 60 Hz

Power consumption:

180 W (0.7 W on standby)

LCD panel:

0.7"(diagonal) polysilicon TFT Wide LCD Panel(x3)

Pixels:

Approx. 1,240,000 pixels

Lens:

Manual zoom(1 - 1.2) / focus lens
F 2.0 - 2.3,  f 22.0 mm - 26.2 mm

Lamp:

120W UHM lamp

Brightness:

700 ANSI lumens

Scanning frequency:
      for RGB signals:

f

H

 30 kHz - 70 kHz,  fv 50 Hz - 87 Hz

YP

B

P

R

 signals:

525i(480i),  625i,  525p(480p),  750p(720p),  1125i(1080i)

Colour system:

NTSC/NTSC4.43/PAL/PAL-M/PAL-N/SECAM

Projection size:

40" - 200" (16:9 Aspect ratio)

Throw distance:

1.2 m - 7.4 m (3'11" - 24'3")

Installation:

Front/Rear/Ceiling/Desk

Audio:

2 W (mono)

Input:
      VIDEO IN:

S-VIDEO : Mini DIN 4-pin
VIDEO : RCA pin jack
AUDIO : RCA pin jack x 2 (L-R)

      PC IN:

RGB : D-SUB HD 15-pin,  AUDIO : Stereo mini Jack

      COMPONENT IN:

RCA pin jack x 3
AUDIO : RCA pin jack x 2 (L-R)

Dimensions

(WxHxD)

:

280 mm (11") x 85 mm (3-11/32") x 242 mm (9-17/32")

(included lens)

Weight:

2.7 kg (6.0 lbs.)

Operating environment:
      Temperature:

0

°

C - 40

°

C (32

°

F - 104

°

F)

      Humidity:

20% - 80% (no condensation)

Supplied Accessories:

AC cord (3m), carrying bag, AV cable (3m),
remote control, lens cap, user’s manual

<Options>
      Ceiling Bracket:

ET-PKE100

      Screen:

ET-SR90CT   W1800mm x H1800mm (70.9"x70.9")
ET-SR70CT   W1400mm x H1400mm (55.1"x55.1")

      Replacement Lamp Unit:

ET-LAE100

Pro je ctio n   se ttin g   e x a m p le

[Dim e n sio n s]

Rear Panel

Projection screen size

(WxH)

Projection distance

1.9m – 2.2m

(6.5' – 7.2')

2.5m – 2.9m

(8.2' – 9.5')

3.1m – 3.7m

(10.2' – 12.1')

4.7m – 5.6m

(15.4' – 18.4')

  60 inches

1328x747mm (4.4'x2.5')

  80 inches

1771x996mm (5.8'x3.3')

100 inches

2214x1245mm (7.3'x4.1')

150 inches

3320x1868mm (10.9'x6.1')

1 6 :9  W ide LCD Panel

Extra Sho rt-thro w Lens

For the fi rst ti me ever i n
the i ndustry, Panasoni c
has empl oyed the 0.7"
N ative Wi de Pol ysi l i con
TFT LCD  Panel  i n the PT-
AE100. Thi s makes for
both a stunni ngl y w i de
screen and superbl y hi gh-
qual i ty pi ctures.
It al so features a
mul ti tude of component
connectors, i ncl udi ng Vi deo, S-Vi deo, Component and PC i nput
termi nal s, so you can now  enj oy the most outstandi ng
w i descreen vi deo experi ence avai l abl e.

The extra-short throw  l ens
makes i t possi bl e to
produce a l arge di spl ay i n
the smal l est of rooms.
Experi ence a l arge screen
w i thout the need of a
huge space. Thi s proj ector
has a footpri nt the si ze of
a l etter pad, but can sti l l
produce a l arge
w i descreen pi cture.
Compare that to the space
taken by a tradi ti onal -technol ogy l arge-screen tel evi si on—and
can that generate an 80" 16:9 di agonal  i mage w i thi n j ust 2.5
metres?

●

Projects high-quality images with a

●

unique optical system.

The new l y devel oped opti cal  system and uni que-to-Panasoni c 120
W  U H M  l amp make bri ghtness and contrast absol utel y opti mum.
A 10-bi t D i gi tal  gamma correcti on ci rcui t real i zes the most true-to-
l i fe col our reproducti on avai l abl e today, w i th ul tra-smooth shadi ng
and i mage generati on.

●

Equipped with a quiet fan and 5000-hour

●

long-life lamp.

* In l ow  pow er mode.

Less noi se and a l onger l i fe.

N oi se has been reduced w i th a new  qui eter fan, and by usi ng tw i n
bl ades, l i ght that l eaks from the gri l l  i s al so cut dow n.

A bui l t-i n cl ock reduces energy consumpti on and extends l amp l i fe
to an amazi ng 5000 hours.

 (Low -mode; 2000 hours i n H i gh-mode.)

280(11")

85(3.35")

243(9.57")

235(9.25")

mm(inch)

●

I ncorporates a widescreen,

●

16:9 aspect ratio LCD  panel.

●

Enables display of larger images in small rooms

●

using an extra-short throw lens.
