21

Underneath existing work top

(

When fitting beneath a work top)

In most modern fitted kitchens there is only one
single work top under which cabinets and
electrical appliances are fitted. In this case remove
the work top of the dishwasher by unscrewing the

screws under the rear edge of the top (

a

).

a

a

b

b

Built-In Installation

(for the

integrated model)

Step 1. Selecting the best location for the dishwasher

The installation position of dishwasher should be near the existing inlet and drain hoses
and power cord.
Illustrations of cabinet dimensions and installation position of  the dishwasher.

1.

  Less than 5 mm between the top of dishwasher and cabinet and the outer door

     aligned to cabinet.

90 °

90 °

580mm

580mm

820mm

820mm

100

100

Electrical, drain
and water supply
line entrances

Electrical, drain
and water supply
line entrances

Space between cabinet

bottom and floor

Space between cabinet

bottom and floor

6 0 0 m m (

f o r

6 0 c m

m o d e l

)

4 5 0

m m

(

f o r

4 5 c m

m o d e l

)

80

80

After removing the work top, the screws must be screwed again under the rear edge
of the top (

b

).

Attention

The height will then be reduced to 815 mm, as scheduled by the International
Regulations (ISO) and the dishwasher will fit perfectly under the kitchen working top
