Sven PS-680 - Инструкция по эксплуатации - Страница 5

ENG

5

User Manual

PS-670, PS-680

g

, CH+: next track (in Player and Bluetooth mode);

Rewind track in Player mode (

long pressing);

Next station (in Radio mode)

h

, AUTO SCAN: Play/Pause button (in Player and Bluetooth

mode);

Start/Stop auto scan (long pressing in Radio mode);

Mute (short pressing in Radio and LINE IN mode)

i

 FM-/+: frequency changeа (in Radio mode)

j

 0-9: numeric pad for entering track number (in Player mode)

or number track/station in Radio mode

Fig. 2.

OPERATION MODES

Bluetooth mode

•

Wireless  data  transfer  via  the  Bluetooth  protocol  enables  to  connect  speaker  system  to

compatible devises. Maximum radius of action of data transfer is 10 m. Such obstacles as walls

or other electronic devices can interfere with the signal transfer.

•

Turn  on  the  speaker  system  Bluetooth  mode  –  press  button  МODE

j

 several times until

display shows «bt» inscription.

•

It  is  necessary  to  select  the  search  mode  of  devices  with  Bluetooth  on  a  signal  source

(telephone, notebook, smartphone, etc.). «SVEN PS-670/680» massage will be displayed on the

screen which is to be connected to*.

•

When  connection  is  successful,  there  will  be  a  short  beep  and  the  indication  of  the  search

mode on speaker system is over**.

* You might have to enter «0000» code to connect some models of devices via Bluetooth.

** If the item has been already registered in the device list of a source, then the second search

mode activation is not obligatory. Choose the item name «SVEN PS-670/680» and the «connect»

command on the source.

CONNECTION AND OPERATION

Attention! The built-in battery must be charged completely prior

to the application.

Speaker system battery charging

•

 Connect speaker system to a USB port of PC or USB charger

using  USB  type  C  to  USB  cable  (included).  During  battery

charging the indicator

h

 is red. Indicator

h

    goes  out  when

the battery is charged.

•

The  battery  is  used  in  the  speaker  system  as  an  integral

part  of  the  device,  therefore  do  not  try  to  extract  or  replace

it,  because  this  can  result  in  the  warranty  cancellation  or  the

device damage.
