SVEN PS-55 - Инструкция по эксплуатации - Страница 4

ENG

4

Portable Speaker System

with Bluetooth and FM-radio

•

The battery is used in the speaker system as an integral part of the device, therefore

do not try to extract or replace it, because this can result in the warranty cancellation

or the device damage.

OPERATION MODES

Bluetooth mode

•

Wireless data transfer via the Bluetooth protocol enables to connect speaker system

to  compatible devises. Maximum radius of action of data transfer is 10 m. Such obstacles

as walls or other electronic devices can interfere with the signal transfer.

•

Turn on the speaker in Bluetooth mode.

•

It is necessary to select the search mode of devices with Bluetooth on a signal source (tele-

phone, notebook, smartphone, etc.). «SVEN PS-55» message will be displayed on the screen

which is to be connected to*.

•

When connection is successful, there will be a short beep and the indication of the search

mode on speaker system is over**.

Radio mode

To improve the quality of radio reception, connect the microUSB ― USB cable (included)

to the microUSB input or the mini-jack signal cable to the mini-jack (included) to the AUX

f

 input.

•

Turn on the speaker system ― press button c several times until, the radio mode will

turn on. Double pressing button

a

 activates auto search mode. After scanning comple-

tion,  the  first  scanned  radio  station  will  start  to  operate  automatically.  With  buttons

b

and

e

 (long pressing) select a desired radio station.

Player mode

Attention! The file system of a micro SD carrier is FAT32. Maximum volume is 32 GB. It is not

recommended to use the micro SD Ultra Speed.

•

The  system  will  enter  the  Player  mode  automatically  when  a  carrier  (USB  flash  or  SD

card) is connected to corresponding ports. Use button

a

 to switch between Play/Pause

modes. You can control tracks by using buttons

b

 (previous track) and

e

 (next track)

(long pressing).

The use in the wired mode (AUX)

•

Connect the 3.5 mm mini-jack cable to the 3.5 mm mini-jack (included) to the AUX

f

input and the 3.5 mm jack to the signal source.

•

Turn on the speaker in AUX mode ― press the button

c

 several times until the speaker

goes into AUX mode.

* You might have to enter «0000» code to connect some models of devices via Bluetooth.

** If the item has been already registered in the device list of a source, then the second

search mode activation is not obligatory. Choose the item name «SVEN PS-55» and the «con-

nect» command on the source.

Connecting an additional speaker

For model «SVEN PS-55» you can connect an additional speaker (Bluetooth mode only):

Attention! Before connecting an additional speaker, disconnect both speakers from the sig-

nal source.
