ENG

4

Portable Speaker System

with Bluetooth and FM-radio

CONNECTION AND OPERATION

Attention! The built-in battery must be charged completely prior to the application.

Speaker system battery charging

•

Connect speaker system to a USB port of PC or USB charger using Type-C to USB cable

(included). When charging, the indicator

k

 lights up in red. Indicator

k

 goes out if the

battery is charged.

•

The battery is used in the speaker system as an integral part of the device, therefore

do not try to extract or replace it, because this can result in the warranty cancellation

or the device damage.

OPERATION MODES

Bluetooth mode

•

Wireless data transfer via the Bluetooth protocol enables to connect speaker system to

compatible devises. Maximum radius of action of data transfer is 10 m. Such obstacles as

walls or other electronic devices can interfere with the signal transfer.

•

Turn on the speakers in Bluetooth mode.

•

It is necessary to select the search mode of devices with Bluetooth on a signal source

(telephone, notebook, smartphone, etc.). «SVEN PS-275» massage will be displayed on

the screen which is to be connected to*.

•

When connection is successful, there will be a short beep**.

Radio mode

To improve radio reception, connect USB-Type-C cable (included) to the input

i

.

•

Turn on the speaker system – press button

f

 several times until, the radio mode will

turn on. Double press button

e

 activates auto search mode. After scanning completion,

the first scanned radio station will start to operate automatically. With buttons

b

 and

c

select a desired radio station.

МР3 player mode

Attention! The file system of a micro SD or USB flash carrier is FAT32. Maximum volume

is 32 GB. It is not recommended to use the micro SD Ultra Speed.

•

Insert the USB flash or micro SD carrier into appropriate slot. If the speaker system is

in turned on position, the playback will start automatically. Playback/Pause modes are

switched over with the help of the button

e

. Tracks can be controlled by buttons

c

(previous track) and

b

 (next track).

Connecting an additional speaker

For model «SVEN PS-275» you can connect an additional speaker (Bluetooth mode only):

•

Connect one speaker to a signal source via Bluetooth.

•

Briefly press button

f

 on the connected speaker, to activate the search mode, the

second speaker must be in the search for BT.

•

The speakers will connect with each other.

Note. At the subsequent inclusion of both speakers, they will be connected

automatically.

* You might have to enter «0000» code to connect some models of devices via Bluetooth.

** If the item has been already registered in the device list of a source, then the second

search mode activation is not obligatory. Choose the item name «SVEN PS-275» and the

«connect» command on the source.
