ENG

14

Portable Speaker System

with Bluetooth and FM-radio

•

The battery is used in the speaker system as an integral part of the device, therefore

do not try to extract or replace it, because this can result in the warranty cancellation or

the device damage.

OPERATION MODES

Bluetooth mode

•

Wireless data transfer via the Bluetooth protocol enables to connect speaker system to

compatible devises. Maximum radius of action of data transfer is 10 m. Such obstacles as

walls or other electronic devices can interfere with the signal transfer.

•

Turn on the speakers in Bluetooth mode – press the button

c

 repeatedly until the button

d

 blinks white short.

•

It is necessary to select the search mode of devices with Bluetooth on a signal source

(telephone, notebook, smartphone, etc.). «SVEN PS-205», massage will be displayed on

the screen which is to be connected to*.

•

When connection is successful, there will be a short beep and the indication of the search

mode on speaker system is over**.

Radio mode

To improve radio reception, connect USB-microUSB cable (included) to the input

i

.

•

Turn on the speaker system – press button

c

 several times until, the radio mode will turn

on. Long-term pressing button

f

 activates auto search mode. After scanning completion, the

first scanned radio station will start to operate automatically. With buttons

e

 and

g

 select a

desired radio station.

МР3 player mode

Attention! The file system of a micro SD or USB flash carrier is FAT32. Maximum

volume is 32 GB. It is not recommended to use the micro SD Ultra Speed.

•

Insert the USB flash or micro SD carrier into appropriate slot. If the speaker system is

in turned on position, the playback will start automatically. Playback/Pause modes are

switched over with the help of the button

f

. Tracks can be controlled by buttons

e

(previous track) and

g

 (next track).

Connecting an additional speaker

It is poddible to connect an additional speaker to the model «SVEN PS-205» (Bluetooth

mode only):

Attention! Before connecting an additional speaker, disconnect first speaker from

signal source.

•

Turn on both speakers (long press button

d

) and select Bluetooth mode. On both speakers,

button

d

�will flash white flashes.

•

On one of the speakers, press and hold the button

c

 until a beep sounds, then release it. The

speakers will connect with each other.

•

On one speaker, button

d

 will glow continuously, on the other speaker, button

d

 will flash

white flashes.

•

Then connect the speaker with the flashing button

d

 to the signal source (see speaker

connection via Bluetooth).

* You might have to enter “0000” code to connect some models of devices via Bluetooth.

** If the item has been already registered in the device list of a source, then the second search

mode activation is not obligatory. Choose the item name «SVEN PS-205» and the “connect”

command on the source.
