Cleaning and Maintenance

Any piece of equipment works better and lasts longer when maintained properly and kept clean. Cooking equipment is no
exception. Your warming drawer must be kept clean and maintained
properly. Make sure all controls are in the “OFF” position.

1.  Allow warming drawer to cool completely.
2.   It is important to keep the slide rails clear and free from debris. Periodic cleaning of slide rails and other adjoining parts is

necessary to assure smooth drawer operation.

3.   If needed, the warming drawer pan support can be removed for cleaning. Pull the warming drawer out until fully extended.

Slide fi nger along right and left side rail until you reach hand latches (located at the front of rails). Pull up on on the left side
latch and press down on the right latch at the same time and pull out the drawer pan.

Removing / Replacing the Drawer

1

2

1

2

Pull out warming drawer pan until fully
extended

Slide fi nger along right and left side until you reach the hand
latches (located approximately in the center of the rail).  Pull up on
on the left side latch and press down on the right latch at the same
time and pull out the drawer pan.

WARNING

To prevent burns, do not remove drawer while hot.
Be sure drawer is empty before removing.

Cabinet mounted
receiver

Drawer mounted
rail

Rail guide on
cabinet mounted
receiver

Ensure the ball bearing retainers are fully extended forward

pror to installing the drawer slides into the cabinet slide

receptacle.  Failure to bring them forward and smoothly

inserted into the drawer will result in physical damage to the

drawer slide assemblies.

NOTE

:  It is important to ensure

that the drawer mounted rail(s) are lined up correctly into the

rail guide(s) of the cabinet mounted receiver in order to avoid

misalignment that will cause slide assembly damage

WARNING

Ball bearing
assembly fully
extended forward
