• it is not subject to traction or torsion;
• it does not get in touch with cutting edges

or corners;

• it can be easily inspected in order to check

its condition.

The control of preservation of the flexible pipe
consists in checking that:
• it doesn't show cracks, cuts, marks of

burning both on the end parts and on its
full extent;

• the material is not hardened, but shows its

normal elasticity;

• the fastening clamps are not rusted;
• expiry term is not due. If one or more ab-

normalities are seen, do not repair the
pipe, but replace it.

• it cannot come into contact with moveable

parts of the appliance;

• it does not pass through any space sus-

ceptible of becoming congested;

Important!

 Once installation is complete,

check the perfect seal of every pipe fitting,
using a soapy solution, never a flame.

Adaptation to different kinds of gas

To adapt the appliance to a different kind of
gas from the one the appliance has been set
for, follow the instructions below in their or-
der.
Gas connection :

LPG

: use the rubber pipe holder, no.4.

Natural gas

 : use the pipe holder, no.5.

Always insert the gasket sealing, no.2. Then
proceed with the gas connection, as indica-
ted in the relevant paragraphs.

1

Gas connection point

2

Gasket

3

Adjustable connection

4

LPG rubber pipe holder

5

Natural gas pipe holder

Hob burners nozzles

Warning!

 Before replacing the nozzles

ensure that the gas knobs are in OFF
position and disconnect the appliance
from the electrical supply.

Nozzles replacement
1. Remove the pan supports.
2. Extract the caps and the wall baffles of

the burners.
