ENGLISH

en

13

Only send the battery pack if the housing is intact

and no fluid is leaking. Remove the battery pack

from the machine for sending. Prevent the contacts

from short-circuiting (e.g. by protecting them with

adhesive tape).

Reducing dust exposure:

WARNING

 - Some dust created by power

sanding, sawing, grinding, drilling, and other

construction activities contains chemicals known to

cause cancer, birth defects or other reproductive

harm. Some examples of these chemicals are:

- Lead from lead-based paints,

- Crystalline silica from bricks and cement and

other masonry products, and

- Arsenic and chromium from chemically treated

lumber.

Your risk from these exposures varies, depending

on how often you do this type of work. To reduce

your exposure to these chemicals: work in a well

ventilated area, and work with approved safety

equipment, such as those dust masks that are

specially designed to filter out microscopic

particles.
This also applies to dust from other materials such

as some timber types (like oak or beech dust),

metals, asbestos. Other known diseases are e.g.

allergic reactions, respiratory diseases. Do not let

dust enter the body.
Observe the relevant guidelines and national

regulations for your material, staff, application and

place of application (e.g. occupational health and

safety regulations, disposal).
Collect the particles generated at the source, avoid

deposits in the surrounding area.
Use suitable accessories for special work. In this

way, fewer particles enter the environment in an

uncontrolled manner.
Use a suitable extraction unit.
Reduce dust exposure with the following measures:

- do not direct the escaping particles and the

exhaust air stream at yourself or nearby persons

or on dust deposits,

- use an extraction unit and/or air purifiers,

- ensure good ventilation of the workplace and keep

clean using a vacuum cleaner. Sweeping or

blowing stirs up dust.

- Vacuum or wash the protective clothing. Do not

blow, beat or brush.

See page 2.

1 Locking screw (diagonal cuts)

2 Scale (diagonal cut angle)

3 Connector (extraction connection piece / chip

ejection)

4 Handle

5 Trigger

6 Locking  button

7 Handle

8 Adjusting screw (adjust saw disc angle)

9 3 Guide grooves to place the machines on

guide tracks from different manufacturers

10 Locking screw (parallel guide)

11 Cutting indicator

12 Parallel stop

13 Battery pack

14 Battery pack release button

15 Guide plate

16 Scale (depth of cut)

17 Storage for hexagon wrench

18 Hexagon wrench

19 Locking lever (depth of cut)

20 Capacity and signal indicator

21 Capacity indicator button

22 Spindle locking button

23 Saw blade fixing screw

24 Outer saw blade flange

25 Saw blade

26 Lever (swivelling back the movable guard)

27 Inner saw blade flange

28 Movable safety guard

Remove the battery pack from the machine

before any adjustment or maintenance is

carried out. Make sure that the tool is switched off

before fitting the battery pack.

6.1 Battery pack

Charge the battery pack (13) before use.
Recharge the battery pack if performance dimin-

ishes.
Instructions on charging the battery pack can be

found in the operating instructions of the Metabo

charger.

Li-Ion battery packs “Li-Power, LiHD“

 have a

capacity and signal indicator (20):

- Press the button (21); the LEDs indicate the

charge level.

- The battery pack is almost flat and must be

recharged if one LED is flashing.

Removal:

Press the battery pack release (14) button and pull

the battery pack (13) upwards.

Inserting:

Slide in the battery pack (13) until it engages.

6.2 Setting cutting depth

Loosen the locking lever (19) for adjustment. Read

the depth of cut that has been set from the scale

(16). Tighten the locking screw again.
It is advisable to set the depth of cut in such a way

that no more than half of each tooth on the saw

blade juts out under the workpiece. See illustration

on page 3.

6.3 Slanting saw blade for diagonal cuts

Loosen the locking screws (1). Tilt the motor part

against the guide plate (15). Read the angle which

has been set from the scale (2). Tighten the locking

screws again.

5. Overview

6. Initial Operation and Setting
