20

When installing cutting blade observe correct direction of the teeth. Arrow on the saw body shows
direction of spindle rotation.

 REPLACEMENT OF CARBON BRUSHES

Replace immediately used up (shorter than 5 mm), burnt or cracked motor carbon brushes. Always replace
both brushes at a time.

Ɣ

Unscrew brush covers (

16

) (

fig. E

).

Ɣ

Remove used brushes.

Ɣ

Remove any carbon dust with compressed air.

Ɣ

Insert new carbon brushes (

fig. F

) (brushes should easily move into brush-holders).

Ɣ

Install brush covers (

16

).

After the brushes are replaced start the power tool with no load and wait until the brushes fit to the
motor commutator. Entrust replacement of carbon brushes only to a qualified person. Only original
parts should be used.

All faults should be repaired by service workshop authorized by the manufacturer.

TECHNICAL PARAMETERS

 RATED PARAMETERS

Circular Saw

Parameter

Value

Supply voltage

230 V AC

Current frequency

50 Hz

Rated power

1200 W

Spindle rotational speed with no load

5000 rpm

Bevel range

0

0

 - 45°

Outer diameter of cutting blade

185 mm

Hole diameter of cutting blade

20 mm

Maximum thickness of cut wood  Right angle

65 mm

Bevel (45

0

)

43 mm

Protection class

II

Weight

3.8 kg

Year of production

2016

NOISE LEVEL AND VIBRATION PARAMETERS

Sound pressure: Lp

A

 = 92.1 dB(A) K = 3 dB(A)

Sound power: Lw

A

 = 103.1 dB(A) K = 3 dB(A)

Vibration acceleration: a

h

 = 2.092 m/s

2

K = 1,5 m/s

2

ENVIRONMENT PROTECTION

Do not dispose of electrically powered products with household wastes, they should be utilized
in proper plants. Obtain information on wastes utilization from your seller or local authorities.
Used up electric and electronic equipment contains substances active in natural environment.
Unrecycled equipment constitutes a potential risk for environment and human health.

* Right to introduce changes is reserved.
