Таблица

 7.

Порты

и

разъемы

 (

продолжение

)

Описание

Значения

Сеть

One RJ-45 port 10/100/1000 Mbps (rear)

USB

●

Without discrete graphics:

○

One USB 3.2 Gen 2 Type-A port with PowerShare (front)

○

One USB 3.2 Gen 2 Type-C port (front)

○

One USB 3.2 Gen 1 Type-A port (rear)

○

Two USB 3.2 Gen 2 Type-A ports (rear)

○

One USB 3.2 Gen 1 Type-A port with Smart Power on
(rear)

●

With discrete graphics:

○

One USB 3.2 Gen 2 Type-A port with PowerShare (front)

○

One USB 3.2 Gen 2 Type-C port (front)

○

Two USB 3.2 Gen 2 Type-A ports (rear)

○

One USB 3.2 Gen 1 Type-A port with Smart Power on
(rear)

Аудио

●

One Universal Audio Jack (front)

●

One Line-out port (retaskable Line-in) (front)

Видео

●

Two DisplayPort 1.4 port (rear)

●

One VGA Port/DisplayPort 1.4 Port/HDMI 2.0b Port/ USB 3.2
Gen 2 Type-C Port with Alt-mode (optional) (Not supported
with Discrete graphics)

●

One Serial RS232 (optional) (Not supported with Discrete
graphics)

●

One Serial/PS2 port (optional) (Not supported with Discrete
graphics)

Устройство

чтения

карт

памяти

Not supported

Разъем

питания

●

4.5 mm DC barrel-type

●

7.4 mm DC barrel-type for 65 W CPU and discrete graphics

Безопасность

One kensington security-cable slot

Антенна

Два

разъема

 SMA (

опционально

)

Внутренние

:

SATA

Два

разъема

 SATA

для

 2,5-

дюймового

жесткого

диска

M.2

●

One M.2 2230 slot for WiFi/Bluetooth card

●

One M.2 2230/2280 slot for PCIe solid-state drive/Intel
Optane

●

One M.2 2280 slot for PCIe solid-state drive/Intel Optane

●

One SATA slots for 2.5-inch hard-disk drive (for 35 W and 65
W only)

●

One half-height Gen3 PCIe x8 slot (discrete graphics)

ПРИМЕЧАНИЕ

:

Подробнее

о

характеристиках

разных

типов

плат

 M.2

см

.

в

статье

базы

знаний

SLN301626

.

Технические

характеристики

21
