6

ENGLISH

(Original instructions)

Explanation of general view

1

Switch trigger

2

Switch button

3

Adjusting dial

4

Change lever

5

Pointer

6

Power-ON indicator lamp
(green)

7

Service indicator lamp (red)

8

Side handle

9

Clamp nut

10 Side grip
11 Bit shank
12 Bit grease
13 Bit
14 Release cover
15 Depth gauge
16 Lock button
17 Blow-out bulb

18 Screws
19 Guard cover
20 Connector
21 Screw
22 Crank cap cover
23 Control plate
24 Crank cap
25 Hammer grease

SPECIFICATIONS

• Due to our continuing program of research and

development, the specifications herein are subject to
change without notice.

• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003

ENE044-1

Intended use

The tool is intended for hammer drilling in brick, concrete
and stone as well as for chiselling work.

ENF002-2

Power supply

The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated and can, therefore, also be used from
sockets without earth wire.

GEA010-1

General Power Tool Safety Warnings

WARNING Read all safety warnings and all

instructions.

Failure to follow the warnings and

instructions may result in electric shock, fire and/or
serious injury.

Save all warnings and instructions for future
reference.

GEB007-7

ROTARY HAMMER SAFETY WARNINGS

1.

Wear ear protectors.

Exposure to noise can cause

hearing loss.

2.

Use auxiliary handle(s), if supplied with the tool.

Loss of control can cause personal injury.

3.

Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring or its own
cord.

 Cutting accessory contacting a “live” wire may

make exposed metal parts of the power tool “live”
and could give the operator an electric shock.

4.

Wear a hard hat (safety helmet), safety glasses
and/or face shield. Ordinary eye or sun glasses
are NOT safety glasses. It is also highly
recommended that you wear a dust mask and
thickly padded gloves.

5.

Be sure the bit is secured in place before
operation.

6.

Under normal operation, the tool is designed to
produce vibration. The screws can come loose
easily, causing a breakdown or accident. Check
tightness of screws carefully before operation.

7.

In cold weather or when the tool has not been
used for a long time, let the tool warm up for a
while by operating it under no load. This will
loosen up the lubrication. Without proper warm-
up, hammering operation is difficult.

8.

Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.

9.

Hold the tool firmly with both hands.

10.

Keep hands away from moving parts.

11.

Do not leave the tool running. Operate the tool
only when hand-held.

Model

HR4003C

HR4013C

HR5202C

HR5212C

Capacities

Carbide-tipped bit

40 mm

52 mm

Core bit

105 mm

160 mm

No load speed (min

–1

)

250 – 500

150 – 310

Blows per minute

1,450 – 2,900

1,100 – 2,250

Overall length

479 mm

599 mm

Net weight

6.2 kg

6.8 kg

10.9 kg

11.9 kg

Safety class

/II
