9 ENGLISH

Dust cup set (optional accessory)

NOTICE:

If you purchase the dust cup set as

optional accessory, the standard side grip cannot

be used with the dust cup set being installed on

the tool.

 When the dust cup set is installed on the

tool, remove the grip from the standard side grip, and

then attach it to the optional grip base set.

►

Fig.12:

1.

 Bolt

2.

 Grip

3.

 Optional grip base set

NOTICE:

Do not use the dust cup set when drill-

ing in metal or similar.

 It may damage the dust cup

set due to the heat produced by small metal dust or

similar. Do not install or remove the dust cup set with

the drill bit installed in the tool. It may damage the

dust cup set and cause dust leak.

Before installing the dust cup set, remove the bit from

the tool if installed.

Install the spacer so that the grooves on the spacer fit

in the protrusions on the tool barrel while widening it.

Be careful for the spring not to come off from the slit of

spacer.

►

Fig.13:

1.

 Spacer

2.

 Spring

►

Fig.14

Install the side grip (optional grip base set and the grip

removed from standard side grip) so that the groove on

the grip fit in the protrusion on the spacer. Turn the grip

clockwise to secure it.

►

Fig.15:

1.

 Side grip

Install the dust cup set so that the claws of the dust cup

fit in in the slits on the spacer.

►

Fig.16:

1.

 Dust cup

2.

 Claw

NOTE:

 If you connect a vacuum cleaner to the dust

cup set, remove the dust cap before connecting it.

►

Fig.17:

1.

 Dust cap

To remove the drill bit, pull the chuck cover down all the

way and pull the drill bit out.

►

Fig.18:

1.

 Bit

2.

 Chuck cover

To remove the dust cup set, hold the root of dust cup

and pull it out.

►

Fig.19

NOTE:

 If the cap comes off from the dust cup, attach

it with its printed side facing up so that groove on the

cap fits in the inside periphery of the attachment.

►

Fig.20

OPERATION

CAUTION:

Always use the side grip (auxiliary

handle) and firmly hold the tool by both side grip

and switch handle during operations.

CAUTION:

Always make sure that the work-

piece is secured before operation.

►

Fig.21

Hammer drilling operation

CAUTION:

 There is tremendous and sudden

twisting force exerted on the tool/drill bit at the time of

hole break-through, when the hole becomes clogged

with chips and particles, or when striking reinforcing

rods embedded in the concrete.

Always use the side

grip (auxiliary handle) and firmly hold the tool by

both side grip and switch handle during opera-

tions.

 Failure to do so may result in the loss of control

of the tool and potentially severe injury.

Set the action mode changing knob to the

 symbol.

Position the drill bit at the desired location for the hole,

then pull the switch trigger. Do not force the tool. Light

pressure gives best results. Keep the tool in position

and prevent it from slipping away from the hole.
Do not apply more pressure when the hole becomes

clogged with chips or particles. Instead, run the tool at

an idle, then remove the drill bit partially from the hole.

By repeating this several times, the hole will be cleaned

out and normal drilling may be resumed.

NOTE:

 Eccentricity in the drill bit rotation may occur

while operating the tool with no load. The tool auto

-

matically centers itself during operation. This does not

affect the drilling precision.

Drilling in wood or metal

CAUTION:

Hold the tool firmly and exert care

when the drill bit begins to break through the

workpiece.

 There is a tremendous force exerted on

the tool/drill bit at the time of hole break through.

CAUTION:

A stuck drill bit can be removed

simply by setting the reversing switch to reverse

rotation in order to back out. However, the tool

may back out abruptly if you do not hold it firmly.

CAUTION:

Always secure workpieces in a

vise or similar hold-down device.

NOTICE:

Never use “rotation with hammering”

when the drill chuck is installed on the tool.

 The

drill chuck may be damaged.

Also, the drill chuck will come off when reversing the

tool.

NOTICE:

Pressing excessively on the tool will

not speed up the drilling.

 In fact, this excessive

pressure will only serve to damage the tip of your drill

bit, decrease the tool performance and shorten the

service life of the tool.

Set the action mode changing knob to the   symbol.

Attach the chuck adapter to a keyless drill chuck to

which 1/2"-20 size screw can be installed, and then

install them to the tool. When installing it, refer to the

section “Installing or removing drill bit”.

►

Fig.22:

1.

 Keyless drill chuck

2.

 Chuck adapter
