Explanation of general view

1

Red indicator

2

Button

3

Battery cartridge

4

Star marking

5

Battery indicator

6

Switch trigger

7

Lamp

8

Reversing switch lever

9

Quick change chuck for SDS-
plus

10 Change cover line
11 Change cover
12 Spindle

13 Quick change drill chuck
14 Rotation with hammering
15 Rotation only
16 Hammering only
17 Grip base
18 Teeth
19 Loosen
20 Tighten
21 Side grip
22 Protrusion
23 Bit shank
24 Bit grease
25 Bit

26 Chuck cover
27

O

 symbol

28 Action mode changing knob
29 Depth gauge
30 Dust cup
31 Blow-out bulb
32 Chuck adapter
33 Drill chuck
34 Sleeve
35 Ring
36 Limit mark
37 Brush holdre cap
38 Screwdriver

SPECIFICATIONS

• Due to our continuing program of research and

development, the specifications herein are subject to
change without notice.

• Specifications and battery cartridge may differ from

country to country.

• Weight, with battery cartridge, according to EPTA-

Procedure 01/2003

ENE043-1

Intended use

The tool is intended for hammer drilling and drilling in
brick, concrete and stone as well as for chiselling work.
It is also suitable for drilling without impact in wood,
metal, ceramic and plastic.

GEA010-1

General Power Tool Safety Warnings

WARNING Read all safety warnings and all

instructions.

Failure to follow the warnings and

instructions may result in electric shock, fire and/or
serious injury.

Save all warnings and instructions for future
reference.

GEB046-2

CORDLESS ROTARY HAMMER SAFETY
WARNINGS

1.

Wear ear protectors.

Exposure to noise can cause

hearing loss.

2.

Use auxiliary handle(s), if supplied with the tool.

Loss of control can cause personal injury.

3.

Hold power tools by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring.

Cutting

accessory contacting a “live” wire may make
exposed metal parts of the power tool “live” and
could give the operator an electric shock.

4.

Wear a hard hat (safety helmet), safety glasses
and/or face shield. Ordinary eye or sun glasses
are NOT safety glasses. It is also highly
recommended that you wear a dust mask and
thickly padded gloves.

5.

Be sure the bit is secured in place before
operation.

6.

Under normal operation, the tool is designed to
produce vibration. The screws can come loose
easily, causing a breakdown or accident. Check
tightness of screws carefully before operation.

7.

In cold weather or when the tool has not been
used for a long time, let the tool warm up for a
while by operating it under no load. This will
loosen up the lubrication. Without proper warm-
up, hammering operation is difficult.

8.

Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.

9.

Hold the tool firmly with both hands.

10. Keep hands away from moving parts.
11. Do not leave the tool running. Operate the tool

only when hand-held.

Model

DHR263

DHR264

Capacities

Concrete

26 mm

Steel

13 mm

Wood

32 mm

No load speed (min

–1

)

0 – 1,250

Blows per minute

0 – 5,000

Overall length

350 mm

374 mm

Net weight

4.6 kg

4.7 kg

Rated voltage

D.C. 36 V
