10
| English
1 609 929 X64 | (24.2.12)
Bosch Power Tools
Delivery Scope
Rotary hammer, auxiliary handle.
Application tools and other accessories shown or described
are not part of the standard delivery scope.
A complete overview of accessories can be found in our ac-
cessories program.
Intended Use
The machine is intended for hammer drilling in concrete,
brick and stone as well as for chiselling.
Technical Data
The technical data of the machine are listed in the table on
page 128.
The values given are valid for a nominal voltage [U] of 230 V.
For different voltages and models for specific countries,
these values can vary.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 24.02.2012
Noise/Vibration Information
The measured values of the machine are listed in the table on
page 128.
Noise and vibrational values (vector sum of three directions)
determined according to EN 60745.
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep hands warm, organise work patterns.
Mounting and Operation
Maintenance and Cleaning
f
For safe and proper working, always keep the machine
and ventilation slots clean.
If the replacement of the supply cord is necessary, this has to
be done by Bosch or an authorized Bosch service agent in or-
der to avoid a safety hazard.
Service Indicator
(see Fig. 9, page 132)
When the carbon brushes are worn out, the machine switches
itself off. This is indicated approx. 8 hours beforehand by the
lighting or blinking of the service indicator. The machine must
then be sent to an after-sales service agent. Addresses are
listed in the Section “After-sales Service and Customer Assist-
ance”.
Service indicator flashes in regular intervals, the machine is
defective. In this case, do not continue to use the machine
and send it immediately to an after-sales service agent.
After-sales Service and Customer
Assistance
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:
www.bosch-pt.com
Our customer service representatives can answer your ques-
tions concerning possible applications and adjustment of
products and accessories.
L
wA
Sound power level
L
pA
Sound pressure level
a
h
Vibration total value
K
Uncertainty
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Engineering Director
PT/ESI
Symbol
Meaning
Action
Figure Page
Insert the SDS-max application tool
1
129
Removing the SDS-max application tool
2
129
Selecting the Operating Mode
3
130
Changing the chisel position (Vario-Lock)
4
130
Changing the position of the auxiliary handle 5
130
Switching On/Off in Drilling Mode
6
131
Switching On/Off in Chiselling Mode
7
131
Adjusting the Speed
8
131
Observing the service indicator
9
132
OBJ_BUCH-1387-002.book Page 10 Friday, February 24, 2012 11:47 AM
