AEG KH 26 E - Инструкция по эксплуатации - Страница 9

16

17

......................... 800 W

......................... 400 W

....................0-1500 min

-1

....................... 1300 min

-1

....................... 4500 min

-1

.......................... 2,9 J

........................... 26 mm

........................... 13 mm

........................... 30 mm

........................... 50 mm

........................... 43 mm

.......................... 2,6 kg

........................... 92 dB (A)

......................... 103 dB (A)

........................... 15 m/s

2

.......................... 1,5 m/s

2

........................ 12,4 m/s

2

.......................... 1,5 m/s

2

ENGLISH

TECHNICAL DATA

Rated input ..............................................................................

Output ......................................................................................

No-load speed .........................................................................

Speed under load max. ...........................................................

Rate of percussion under load max. ........................................

Single impact strength .............................................................

Drilling capacity in concrete .....................................................

Drilling capacity in steel ...........................................................

Drilling capacity in wood ..........................................................

Light core cutter in bricks and limestone .................................

Chuck neck diameter ...............................................................

Weight without cable ...............................................................

Noise Information

Measured values determined according to EN 60745.

Typically, the A-weighted noise levels of the tool are:

  Sound pressure level (K = 3 dB(A)) .......................................

  Sound power level (K = 3 dB(A)) ............................................

Wear ear protectors!

Vibration Information

Total vibration values (vector sum in the three axes)

determined according to EN 60745.

Vibration emission value a

h

:

Hammer-drilling in concrete: vibration emission value a

h

 .......

Uncertainty K =  .......................................................................

Chiselling: vibration emission value a

h

 ....................................

Uncertainty K =  .......................................................................

 WARNING! Read all safety warnings and all

instructions, including those given in the accompanying

brochure

. Failure to follow the warnings and instructions

may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

SAFETY INSTRUCTIONS

Wear ear protectors.

 Exposure to noise can cause hearing

loss.

Use auxiliary handles supplied with the tool.

 Loss of

control can cause personal injury.

Hold power tool by insulated gripping surfaces, when

performing an operation where the cutting accessory

may contact hidden wiring or its own cord.

 Contact with

a „live“ wire will also make exposed metal parts of the power

tool „live“ and shock the operator.
Appliances used at many different locations including open

air should be connected via a residual current device of

30 mA or less.
Always wear goggles when using the machine. It is

recommended to wear gloves, sturdy non slipping shoes

and apron.
Sawdust and splinters must not be removed while the

machine is running.
Always disconnect the plug from the socket before carrying

out any work on the machine.

Only plug-in when machine is switched off.
Keep mains lead clear from working range of the machine.

Always lead the cable away behind you.

When working in walls ceiling, or floor, take care to avoid

electric cables and gas or waterpipes.
The dust produced when using this tool may be harmful to

health. Do not inhale the dust. Wear a suitable dust

protection mask.
Under the effect of extreme electromagnetic interferences

from the outside, temporary variations in the speed of

rotation could arise in particular cases.

SPECIFIED CONDITIONS OF USE

The rotary pneumatic hammer can be used for hammer

drilling, chiselling in stone and concrete and drilling in wood,

metal as well as plastic.
Do not use this product in any other way as stated for

normal use.

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given

in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained, the vibration emission may differ. This may significantly increase

the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may significantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work patterns.

ENGLISH

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that this product is

in conformity with the following standards or standardized

documents. EN 60745, EN 55014-1, EN 55014-2,

EN 61000-3-2, EN 61000-3-3, in accordance with the

regulations 98/37/EC, 2004/108/EC

Rainer Kumpf

Manager Product Development

Winnenden, 2009-03-11

MAINS CONNECTION

Connect only to single-phase a.c. current and only to the

system voltage indicated on the rating plate. It is also

possible to connect to sockets without an earthing contact

as the design conforms to safety class II.

MAINTENANCE

The ventilation slots of the machine must be kept clear at all

times.
Important note! If the carbon brushes are worn, in addition

to exchanging the brushes the tool should be sent to after-

sales service. This will ensure long service life and top

performance.
Use only AEG accessories and spare parts. Should

components need to be replaced which have not been

described, please contact one of our AEG service agents

(see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.

Please state the Article No. as well as the machine type

printed on the label and order the drawing at your local

service agents or directly at: AEG Elektrowerkzeuge,

Max-Eyth-Straße 10, D-71364 Winnenden, Germany.

SYMBOLS

Please read the instructions carefully before

starting the machine.

Always disconnect the plug from the socket

before carrying out any work on the

machine.

Accessory - Not included in standard

equipment, available as an accessory.

Do not dispose of electric tools together

with household waste material! In

observance of European Directive 2002/96/

EC on waste electrical and electronic

equipment and its implementation in

accordance with national law, electric tools

that have reached the end of their life must

be collected separately and returned to an

environmentally compatible recycling

facility.
