Hoover CA2IN1D - Инструкция по эксплуатации - Страница 4

2

USING YOUR CLEANER

BEFORE YOU BEGIN CLEANING

1.  Release the clean water tank by sliding the water release button upwards and

remove tank from cleaner main body.

[5]

2.  Pull the cap on the Water Tank to open.

[6]

3.  Fill the clean water tank with cold tap water. Replace cap

[7]

 and refit water tank.

Do not add any chemicals, detergents or perfumes to the clean water tank.

NOTE:

 In order to significantly reduce mineral build-up and prolong the life of your steam

mop the use of distilled or de-mineralized water in the unit is highly recommended.

4.  Attach a Textile Pad to the base of the Floor Head.

[8]

IMPORTANT: Always unplug the cleaner when adding water or changing a Textile Pad.
NOTE: Wash the Textile Pad prior to use to remove any lint.

STEAM CLEANING HARD FLOORS

NOTE: Always sweep or vacuum the floor prior to use to remove any loose

dirt or debris.

IMPORTANT: Do not use the cleaner without a Textile Pad attached to the

Floor Head.

NOTE:

Do not use the Carpet Glider when cleaning hard floors.

1.  Plug the steam cleaner into the main power. Press the power on/off button, the

power on light (red) will illuminate.

2.  After a few seconds the steam ready light (green) will illuminate indicating the

cleaner is ready for use.

3.

Recline  the  cleaner  by  placing  a  foot  on  the  floor  head  and  lowering  the  main  body
towards the floor.

[11]

4.  To produce steam press the Steam Trigger Button.

[12]

5.

Move the cleaner slowly backwards and forwards paying particular attention to high
traffic areas.

[13]

6.

Variable steam release control are used to select Low, Medium or High volume of
steam, depending on your specific cleaning requirement.

[14]

Steam cleaning hard floor - intensive clean

Use the triangular floor brush for hard floors that require deep cleaning. Please note that

there is no mop and the area will have to be dried separately.

NOTE:

Always sweep or vacuum the floor prior to use to remove any loose dirt or debris.

1.  Remove the triangular floor brush from the floor head by pressing the release pedal

at the rear of the floor head.

 [15]

2.  Plug the steam cleaner into the main power. The power on light (red) will illuminate.

After a few seconds the green Steam Ready light will illuminate indicating the
cleaner is ready for use.

3.  Recline the cleaner by placing a foot on the floor brush and lowering the main body

GETTING TO KNOW YOUR CLEANER

A.  Steam Release Trigger
B.  Handle Assembly
C.  Upper&Lower Cord Storage Hooks
D.  Power Cord
E.  Handheld Release Button
F.

Handheld Steam Release Trigger

G.

Cleaner Main Body

H.  Triangular Brush Release Pedal
I.

Triangular Brush

I2

  Floor Head*

J.

Handle Fix Location

K.

Variable Steam Release Control Slider Low, Medium &

High

L.

Power On Indicator Light ( Metallic Red )

M.

Steam Ready Light ( Green )

N.  Power On /Off Button
O.  Clean Water Tank
P.  Clean Water Tank Release Button
Q.  Conic Tool
R.  Hose
S.  Curved Nozzle
T.

Round Brush

U.

Small Metal Brush

V.

Big Metal Brush

W.  Window Squeegee

X.

Small Cloth

Y.  Textile Pad
Z.

Carpet Glider

AA.  Carpet Glider Release Pedal
AB.  Bolt

ASSEMBLING YOUR CLEANER

Remove all components from the packaging.

1.

Line up the ergonomic handle to the main body of the cleaner and fix in position with

the supplied Bolt.

[1,2]

2.  Assemble the main body of the cleaner to the Triangular Brush.

[3]

3.

Assemble the main body of the cleaner to the floor Head or assemble the Triangular

Brush into the Floor Head*.

 [4]

GB

*Certain Models Only
