Seagate SkyHawk Product Manual, Rev. A

12

www.seagate.com

Drive Specifications

2.7

Power specifications

The drive receives DC power (+5V or +12V ) through a native SATA power connector. Refer to

Figure 2 on page 18

.

2.7.1 Power consumption

Power requirements for the drives are listed in

Table 2

 and

Table 3

. Typical power measurements are based on an average

of drives tested, under nominal conditions, using 5.0V and 12.0V input voltage at 25°C ambient temperature. These power
measurements are done with DIPM enabled.

• Spinup current is measured from the time of power-on to the time that the drive spindle reaches operating

speed.

• Operating Power is measured following IDEMA 3 streams standard, assuming CE operating condition

• The drive supports three idle modes: Performance Idle mode, Active Idle mode and Low Power Idle mode.

Refer to

Section 2.7.4

 for power-management mode.

2.7.2 Conducted noise

Input noise ripple is measured at the host system power supply across an equivalent 80-ohm resistive load on the +12 volt
line or an equivalent 15-ohm resistive load on the +5 volt line.

• Using 12-volt power, the drive is expected to operate with a maximum of 120 mV peak-to-peak square-wave injected

noise at up to 10MHz.

• Using 5-volt power, the drive is expected to operate with a maximum of

100 mV peak-to-peak square-wave injected

noise at up to 10MHz.

Table 2

DC power requirements (8TB & 6TB)

Power dissipation

Avg (watts 25° C)

Avg 5V typ amps

Avg 12V typ amps

Spinup

—

—

1.8

Idle, Low Power

3.4

0.10

0.242

Operating Power

5.3

0.28

0.325

Standby

0.25

0.04

0.004

Sleep

0.25

0.04

0.004

Table 3

DC power requirements (4TB, 3TB & 2TB)

Power dissipation

Avg (watts 25° C)

Avg 5V typ amps

Avg 12V typ amps

Spinup

—

—

1.8

Idle, Low Power

2.5

0.12

0.15

Operating Power

3.7

0.28

0.191

Standby

0.25

0.04

0.004

Sleep

0.25

0.04

0.004

Note

Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current.
