DESCRIPTION

SPECIFICATIONS

KVR26S19S6/8

8GB 1Rx16 1G x 64-Bit PC4-2666
CL19 260-Pin SODIMM

Continued >>

FEATURES

This document describes ValueRAM's KVR26S19S6/8 as a 1G
x 64-bit (8GB) DDR4-2666 CL19 SDRAM (Synchronous
DRAM), 1Rx16, memory module, based on four 1G x 16-bit
FBGA components. The SPD is programmed to JEDEC
standard latency DDR4-2666 timing of 19-19-19 at 1.2V. This
260-pin SODIMM uses gold contact fingers. The electrical and
mechanical specifications are as follows:

CL(IDD)
Row Cycle Time (tRCmin)
Refresh to Active/Refresh
Command Time (tRFCmin)
Row Active Time (tRASmin)
UL Rating
Operating Temperature
Storage Temperature

19 cycles
45.75ns(min.)
350ns(min.)

32ns(min.)
94 V - 0
0

o

 C to +85

o

 C

-55

o

 C to +100

o

 C

•   Power Supply: VDD = 1.2V Typical

•   VDDQ = 1.2V Typical

•   VPP = 2.5V Typical

•   VDDSPD = 2.2V to 3.6V

•   Nominal and dynamic on-die termination (ODT) for
    data, strobe, and mask signals

•   Low-power auto self refresh (LPASR)

•   Data bus inversion (DBI) for data bus

•   On-die VREFDQ generation and calibration

•   Single-rank

•   On-board I2 serial presence-detect (SPD) EEPROM

•   8 internal banks; 2 groups of 4 banks each

•   Fixed burst chop (BC) of 4 and burst length (BL) of 8
    via the mode register set (MRS)

•   Selectable BC4 or BL8 on-the-fly (OTF)

•   Fly-by topology

•   Terminated control command and address bus

•   PCB:  Height 1.18” (30.00mm)

•   RoHS Compliant and Halogen-Free

Document No. VALUERAM1639A     08/19/20     Page 1
