www.timberk.com • Electric fan heater

4

4. OPERATION CONDITIONS

5. APPEARANCE AND COMPONENTS

1. Do not install the unit on unstable or uneven surfaces.
2. To prevent an electric shock, do not connect and disconnect the power

cord plug out of an outlet by wet hands.
3. For normal operation of the unit the mains voltage must be sufficient in

strict compliance with technical parameters indicated on the unit.
4. The unit must be mounted vertically only. NEVER USE THE UNIT IN A

HORIZONTAL OR INCLINED POSITION.
5. Do not use the unit in a room with high dust content. Otherwise, high

amount of dust in the unit may cause its failure and voiding of guarantee

maintenance.

1. On/Off power switcher
2. Control panel
3. Heating element
4. Front protective grille
5. Stand

NOTE:

Timberk MMA Company disclaims any liability for
possible damage, directly or indirectly caused by
Timberk products to people, pets, property in case if
it occurred as a result of failure to observe rules and
conditions of operation, unit’s installation, deliberate or
careless actions of the consumer of third parties.

NOTE:

Appearance of smell/smoke is possible at first use.
Do not care, this means that an oil drop got onto the
glowing spiral during manufacturing. The drop will
quickly evaporate and no smoke/ smell will appear
anymore.

3. WORKING PARAMETERS

Main features

1. The fan heater is convenient to be placed in any room where additional

air heating is required.
2. Durable and flameproof metal-ceramic heating element provides quick

and effective air heating, doesn’t pollute the environment and doesn’t burn

oxygen.
3. Direct current electric motor with low noise.
4. A fuse and thermal limiter protect the fan heater from overheating.
5. LED-display.
6. RC included in delivery set.
7. Timer function for 9 hours and simple operation of appliance

For a detailed description of technical parameters and characteristics go to

www.timberk.com or contact TIMBERK official dealers.

Technical parameters

Table 1

Description

TFH T20FSN.LZ

Nominal power consumption

W

2000

Rated current

A

9,1

Rated voltage

V/Hz

~220/50

Water protection class

IPx0

Electric protection class

Class II

Noise level

dB

55

Heating area

m2

22-25

Weght

kg

2,0

Dimensions

mm

560x220x155
