www.timberk.com • electric convector heater
5
Wall mounting of the convector (Fig.3,4,5)
dimensions are
given in mm.
1. Convector - 1pcs.
2. Castors - 2 pcs.
3. Remote control - 1pcs.
4. Manual instruction - 1pcs.
5. Warranty card - 1pcs.
6. Packing - 1pcs.
7. Installation kit - 1pcs.
NOTE:
To improve products quality, design and technical
characteristics of the convector, as well as its scope
of delivery may be altered by the manufacturer
without prior notification.
6. INSTALLATION
5. COMPLETE SET
1. Open the factory package and carefully remove the unit out of it.
2. Remove seals out of foamed plastic on sides of the unit and take it out
of polyethylene.
3. In accordance with Fig. 2, 3 and table 2, determine the place of
convector’s installation observing minimum distances from objects and
minimum distance from the floor.
4. Mark the height, at which the convector is to be mounted, then attach
bracket to the wall.
5. Put visible marks in mounting holes.
6. Drill holes of the required diameter on the mounting holes, insert dowels,
attach the mounting bracket and fasten adjusting screws, thereby
securing bracket on the wall (Fig. 5).
Fig. 2
Fig. 3
IMPORTANT!
DO NOT COVER THE UNIT. Do not dry clothes and any
other fabrics and materials on the unit. It may cause its
overheating, failure or inflict significant damage to you
and/or your property.
Leg mounting of the convector (Fig. 4)
1. Take 2 legs out of a package box.
2. Turn over the unit so that its lower part was at the top.
