Operation and Storage Manual

5

EN

English

a pulling rope in order to move the panel heater;
any movement of the panel heater should be done
when it is cold.

 •

Position the panel heater with installed feet on the
floor and before connecting it to the power socket
check if all instructions from the very beginning of
this manual have been followed correctly (Important
instructions and safety measures). The correct
position is – the control panel should be at the top of
the appliance and the feet – on the floor!

BATHROOM OPERATION

 •

The panel heater must be installed in accordance
with the normal trade practices and in compliance
with the national legislation (EU electricity directives
and regulations concerning special installations and
places of operation including bathrooms, shower
cabins HD60364-7-701(IEC 60364-7-701:2006)).

 •

In case this panel heater is to be used in a bathroom
or other similar room, the following installation
requirements must be observed: the panel heater
is with IP24 protection (water drops protection).
Hence it can be installed in “Volume 2” (see the
diagram below) in order to avoid the risk of the
control board (power switch and thermo regulator)
being reached by a person who is in a shower or

a bathtub. The minimum distance between the
appliance and a water source should be not less
than 1 meter! If you do not feel sure about the
installation of this panel heater in a bathroom,
we recommend you to consult a professional
electrician.

Note

: If the above-mentioned instructions cannot be

implemented, it is recommended to install the appliance

in “VOLUME 3”.

 •

In wet premises the power source must be installed
at a height of at least 25 cm above the floor
(bathrooms and kitchens).

 •

The installation must be equipped with a safety
fuse, and the distance between the fuse contacts in
disconnected condition should be at least 3 mm.

OPERATION INSTRUCTIONS

MECHANICAL CONTROL

Operation modes

Turn the panel heater on by pushing the switch in
position “I” (turned-on), then turn the regulator to
the desired level (1 to 6) as you take into account the
following relation between the power levels:

* – anti-freezing mode/ enabled when room
temperature falls below 5°C

1 / 2

– economy mode/ it maintains low room

temperature/ this mode is recommended to be used
at night and when there are no people present in the
room. This mode permits to maintain the set room
temperature while saving energy.

3 / 4 / 5

 – comfort mode/ it maintains moderate room

temperature/ this mode is recommended to be used to
maintain relatively high comfortable room temperature
during the day.

6

 – maximum power mode / it maintains HIGH room

temperature/ this mode is recommended to be used
when you need maximum high room temperature

Important:

Thermo Regulator digits do not correspond

to certain room temperature levels, but they can be used

by users to memorize the relation between room temperature
and the thermo regulator settings.
