Usage and Storage Instructions

EN

EN

OPERATION

Turning-on

Put the plug into the socket, turn thermostat knob

clockwise and turn the appliance on as follows:

 •

Only button (I) is turned-on – light heating –

MIN (W)

;

 •

Only button (II) is turned-on – medium heating –

MED (W)

;

 •

Both buttons are turned-on – intense heating –

MAX (W)

;

Power values of the corresponding levels (

MIN(W)

,

MED(W)

,

MAX(W)

) are shown in table.

Model

MAX(W)

MED(W)

MIN(W)

1005

1000 W

600 W

400 W

1006

1000 W

600 W

400 W

1506

1500 W

900 W

600 W

1507

1500 W

900 W

600 W

1508

1500 W

900 W

600 W

2008

2000 W

1200 W

800 W

2009

2000 W

1200 W

800 W

2010

2000 W

1200 W

800 W

2011

2000 W

1200 W

800 W

2012

2000 W

1200 W

800 W

2510

2500 W

1500 W

1000 W

2511

2500 W

1500 W

1000 W

2512

2500 W

1500 W

1000 W

2513

2500 W

1500 W

1000 W

2514

2500 W

1500 W

1000 W

3012

3000 W

1800 W

1200 W

3013

3000 W

1800 W

1200 W

3014

3000 W

1800 W

1200 W

To turn off the appliance turn off the two buttons and

take the plug out of the socket outlet.

Thermoregulator adjustment

Power switch and thermoregulator should be set to

maximum position until the desired room temperature

is reached. Then turn thermoregulator switch in the

opposite direction till red light indicator goes down.

Thermoregulator may stay in that position after that.

Immediately after room temperature falls below

thermoregulator value thermal switches are turned on

automatically until set temperature is reached. In that

way room temperature is steady with  minimum energy

consumption.

If you want to prevent temperature fall in the room

below 0 degrees Centigrade adjust thermostat switch in

its initial position and turn on the two power buttons.

24-hours timer models (“T”)

Adjust the heating period in the following consequence:

 •

Set the clock to the correct

time. If it is 10 o’clock turn the

figures dial so that the mark is

positioned to the figure of 10.

Turn the figures dial only in the direction indicated

with arrows! Adjust the period of operation of the

appliance by pushing black keys to the center – every one

of them corresponds to 15 minutes period. Sector of the

pushed keys will correspond to the period of operation of

the radiator in automatic mode every day.

Important :

Plug should always be connected to the

socket outlet!

 •

In order to change programmable period of

automatic operation turn black keys backwards and

adjust new periods of operation.

 •

If you do not want the appliance to operate in

programmable mode push all black keys to the

center of the figures dial. To turn off the radiator in

that case you have to pull the plug out of the socket.

In that way unnecessary operation of the timer is

avoided.

Thermal fan models (“V”)

Models equipped with a 500W thermal fan offer

faster achievement of desired temperature and better

ventilation in the room. Thermal fan may function

separately or together with oil-filled radiator. Thermal

fan is positioned in the bottom part of the front panel

of the radiator and is turned on by a switch positioned

in that part of the panel. Cold air is sucked through the

grating in the front part of the front panel and hot air is

released in the room through the grating positioned in

the bottom side part of the radiator panel. Desired room

temperature with thermal fan operation is adjusted by

thermoregulator of the radiator in the above mentioned

manner. For the normal operation of the thermal fan

it is necessary that air passes unobstructedly through

inlet and outlet grating. Electrical device is intended

for domestic use in premises with low level of dust

pollution. Dust is accumulated after certain period

of operation. In is necessary to check periodically

level of pollution and if needed to consult the service

organization for cleaning.
