• The appliance is only to be used in the home for the purposes described

in these instructions. Unauthorised use and technical modifications to the
appliance can lead to danger to life and health.

• Never submerge the unit in water (danger of short circuiting).

• Never run a defective unit (e.g. supply cord).

• Never touch energized parts.

• Only connect the cable to alternating current. Observe the voltage infor-

mation given on the appliance. Do not use extension cords.

• The heater must not be located directly below a socket-outlet.

• Do not open the appliance (repairs only by service agents).

• Do not use this heater in the immediate surroundings of a bath, a shower

or a swimming pool (the appliance is not splash-proof).

• Do not run the power cord over sharp edges and make sure that it does

not get trapped. Do not pull the plug from the socket with wet hands or by
holding on to the power cord.

• Do not place the appliance near a heat source. Do not subject the power

cord to direct heat (such as a heated hotplate, open flames, hot iron sole
plates or heaters for example). Protect power cords from oil.

• Please make sure that the used socket remains accessible.

• Do not run the heater on an uneven or soft surface.

• CAUTION: In order to avoid a hazard due to inadvertent resetting of the

thermal cut-out, this appliance must not be supplied through an external
switching device, such as a timer.

• WARNING: In order to avoid overheating, do not cover the air inlet or air

outlet - fire hazard!

• Do not use the heater in small rooms (below 4 m

2

 in size), in explosive

environment, or for drying laundry.

• Do not touch the front grille, it might reach hot temperature.

• Use the heater only under supervision.

• Do not insert any object and/or finger into the openings of the heater.

• To extinguish burning appliances only use fire blankets.

Setting up / operation

1. Having set up the Max heater in the desired position, insert the mains

cable (7) into the mains socket (6) on the appliance and connect the cable
(7) to the household supply socket.

2. Switch on the Max to the desired level by means of the rotary control (1).
3. Rotary control (1):


Position 0

=

Off

Position

=

Ventilation, turn the room-thermo-

stat rotary control (2) clockwise as

far as the stop

Position  I

=

Heating,  800 W

Position II

=

Heating, 2000 W

4. Room thermostat (2):  The room-thermostat control (2) allows for a vari-

able temperature adjustment.

  Setting: for maximum temperature, turn the control clockwise,
  for minimum temperature, turn the control anti-clockwise.
  Recommendation: Turn the thermostat control (2) clockwise as far as
  the stop. If the desired room temperature has been reached, turn the
  thermostat control (2) anticlockwise until the appliance switches off.

  If the room temperature drops, then Max switches on again automati-
  cally. Please note that after the thermostat switches off automatically, it
  takes a few minutes for the heater to switch on again!
5. Frost-protection circuit

*

: Set the room-thermostat control (2) to

*

. To

prevent the room temperature from falling below approx. +5°C, set the
rotary control (1) to position I or II (depending on the size of room, Position
II for larger rooms) and the room-temperature control (2) to

*

. The appli-

ance switches on automatically at approx. +5°C and off again at approx.
+7°C. In this way, frost damages can be avoided.

6. Protection against over-heating: Max is fitted with an over-temperature

safety device which switches off the appliance in the case of a technical
fault or improper use. Should this occur, pull the mains cable (6) out of
the supply socket and remedy the fault or correct the method of use. The
appliance can be put back into use when it has cooled down and has been
disconnected from the mains supply for a short time.

Note: Make sure that there is always sufficient space between the
appliance and the wall or other large objects (> 50 cm). The air flow
must not be blocked by objects of any kind.

Cleaning

Before servicing the heater and after each occasion of use, switch off the
appliance and unplug the mains cable from the socket.

• Attention: Never immerse the appliance in water (danger of short-circuit).

• To clean the appliance, only wipe it down with a damp cloth and then dry

it carefully.

• Take care that the air intake and outflow grilles do not become exces-

sively dusty; clean them occasionally with a dry brush or vacuum cleaner.

Repairs

• Repairs to electrical appliances must only be carried out by a qualified

electrical technician. If improper repairs are carried out, the warranty
lapses and all liability is refused.

• Never operate the appliance if the adaptor or plug is damaged, after it has

malfunctioned, if it has been dropped or has been damaged in any other
way (cracks/breaks in the casing).

• Do not push any object into the appliance.

• If the appliance is beyond repair, make it unusable immediately by cutting

through the cable and hand it in at the collection point provided for the
purpose.

Disposal

The European directive 2012 / 19 / CE on Waste Electrical and Electronic
Equipment (WEEE), requires that old household electrical appliances must
not be disposed in the normal unsorted municipal waste stream. Old appli-
ances must be collected separately in order to optimize the recovery and
recycling of the materials they contain and reduce the impact on human
health and the environment. The crossed out “wheeled bin” symbol on the
product reminds you of your obligation, that when you dispose of the appli-
