ENGLISH

4. INSTALLATION

Before starting the convector, the base must be fi tted.

Fitting the base

Fit the base supports to the side (Fig. 3) and secure each one with four small screws.

5. SWITCHING ON AND OPERATION

Once you have checked that the mains voltage coincides with the voltage indicated on the
name plate, connect the convector.

1.  Select the power using the power selector command and turn the thermostat command in

the direction of clockwise to its maximum position (Fig. 2).

0

OFF

I

Low power

II

Medium power

III

High power

2.  Once the room has reached the desired temperature, turn the thermostat control anti-

clockwise until you hear a slight click. When the thermostat control is in this position, the
convector will connect and disconnect automatically to keep the pre-selected temperature
constant.

6. COMBINED OPERATION (only TLS-503T model)

To accelerate the heating of the room you can also connect the fan by pressing the fan switch.
In this position the switch will light up.

7. ANTI-FREEZE PROTECTION

The S&P convectors incorporate an anti-freeze device which triggers the convector when the
room temperature drops below +5ºC.
To activate this device just connect the convector to the mains, place the power selector in any
of the active positions and the thermostat control in the

 position (Fig. 2).

The convector will remain disconnected until the room temperature drops below +5ºC when
it will start automatically to ensure the temperature is maintained over +5ºC.
This device is particularly useful in places where low temperatures are common and the
water pipes are likely to freeze, etc.
