7.

Electric ceiling heater

EN

6. INSTALLATION

6.1 Safe distances required for installation

1. Expand the original packaging and carefully remove the heater

2. Remove the mounting kit

3. Collect the installation wall mount holes as shown in Fig. 2

4. Connect the hardware to the instructions shown in Fig. 3, 4, 5

5. Hang the heater on the smooth surface of the wall with the observance of the distance spec-

ified in item 6.1. Make sure that the mounting screws firmly fastened

6. If necessary, install the heater, bracket, follow the instructions shown on Fig. 6, 7, 8, 9 and

specified in item 6.3

6.2 Installation of the heater using the wall fasteners

Table 2

On Fig. 2, 3, 4, 5 shows stepwise instructions on assembly and installation of wall fasteners for

infrared heater.

NOTE:

To improve the product quality, the design and technical specifications

of the infrared heater, as well as its delivery set can be modified by

the manufacturer without preliminary notification.

NOTE:

Depending on material and design of ceiling structural elements, the

heater is secured onto appropriate fasteners chosen on basis of the

strength  condition.  Strength  of  the  ceiling  or  structural  elements,

to which the heater is secured, should be sufficient to endure 5-fold

weight of the heater.

№

Parts name

Specification

Qty

1

Screw

M6x20

1

2

Bracket set

Aluminum

1

3

Expansion bolt

M6x60

2

4

Hanger

STEEL

1

5

Bolt

M8х60

1

5A

Nut

M8

1

5. DELIVERY SET

1. Infrared heater – 1 pcs.

2. Fasteners kit – 1 pcs.

3. Operation manual and warranty certificate – 1 pcs.

4. Package – 1 pcs.
