10.

Electric ceiling heater

EN

ATTENTION!

The  power  outlet  should  be  rated  at  least  10A  for  models  with  a

maximum capacity of up to 1800 W and at least 16A for models with

a maximum capacity of more than 1800 W.

5. CONNECTING TO THE MAINS

1. The heater is designed for connection to the single-phase ~220 V, 50 Hz electric mains equipped
with a grounding loop.

2. Before connection, make sure that speciications of the electric mains at the connection point

meet the parameters indicated on the appliance nameplate.
3. The electric mains should be equipped with an automatic circuit breaker with rated current not
less than 16A
4. For connection of the heater to the electric mains, it is necessary to do the following:

• remove the cover from the heater, cut a hole in the rubber seal, insert the electric cable to the
heater, tightly ix the bare ends of the electric cable in the junction block of the heater with screws

in strict correspondence with marking on the block, reinstall the cover.

NOTE:

The  instruction  manual  for  remote  control  block  is  not  included  in

the scope of delivery. Should be bought separately.

ATTENTION!

Ater installation of the heater and before switching for the irst time,

it is necessary to wipe the radiating board with alcohol. Ater that, it is

PROHIBITED to touch the radiating board.

NOTE:

1. Depending on material and design of ceiling structural elements,

the  heater  is  secured  onto  appropriate  fasteners  chosen  on  basis

of  the  strength  condition.  Strength  of  the  ceiling  or  structural

elements,  to  which  the  heater  is  secured,  should  be  suicient  to

endure 5-fold weight of the heater.
2. The heater can be installed on the wall and mounted on the height

not less than 1.8 from the loor. Also it is obligatory to be installed

an  additional  protection  in  order  to  avoid  the  contact  with  heating

plates.
