Thermowarm TWT/TWTC

5

GB

Thermovarm is a small and neat ribbed pipe
radiator. It is especially suitable for spaces
where relatively high output is needed but
there is limited space. The front plate is re-
movable, which makes the radiator easy to
clean. TWT has sides of grey thermo plastic
and either a lacquered or locked front plate.

TWTC has sides of black thermo plastic and

front plate, inner sides, brackets and elements
are in lacquered corrosion proof design.

Mounting

The radiator is attached to the wall with four
screws. There is a template for placing the
screws on the bottom of the carton. Stick a
sharp instrument through the marks on the
carton to mark where to place the screws.
The two upper holes are “keyholes”. See
sketches on page 2. Electrical connection of
TWT100 and TWT200 must be permanent
and done by an authorized electrician.

Versions

• TWT100 is equipped with thermostat and

output switching 0-1/1. 230V or 400V.
Protection class IP44.

• TWT300 is equipped with thermostat, cord

and plug. Available in 230V only.
Protection class IP 21.

• TWT200 is equipped with thermostat and

output switching 0-1/1. 230V or 400V.
TWT200 has locked front plate and is
approved for use in children’s rooms and in
household personal hygiene rooms where
there is a maximum temperature of 60°C.
Protection class IP44.

• TWTC is equipped with thermostat, cord

and plug. Available in 230V only. TWTC is
in corrosion proof design.
Protecion class IP54.

Thermostat

The thermostat is of the capillary tube type
and adjustable between 0-35°C.

TWT:
A Celsius scale is marked on the side of the
thermostat dial. The dial is on the right side

of the heater.

The scale of the thermostat dial can be tur-

ned to calibrate the thermostat to the room
temperature in question.

TWTC:
The thermostat is protected under a threaded
lid on the right side of the heater. The lid can
be removed by a screwdriver. See sketch on
page 2 for thermostat setting. The thermo-
stat is set by turning the notch to the desired
temperature.

Overheat protection

TWT:
The overheat protection can be reset by
pushing the button on the right end plate of
the heater.

TWTC:
The overheat protectionis protected under a
threaded lid on the right side of the heater.
The lid can be removed by a screwdriver. The
overheat protection is reset by pushing the
button.

Cleaning

Remove dust with a vacuum cleaner or a soft
brush.

For the 200 series with locked front plate:

The surface can be washed with mild soap
solution or carpet foam. Remove spots with
chemically pure petrol. Avoid strong solvents
such as acetone and similar.

Safety

  This appliance is not intended for use by

persons (including children) with reduced
physical or mental capabilities, or lack
of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a per-
son responsible for their safety. Children
should be supervised to ensure that they do
not play with the appliance.

Mounting and assembly
