SF WL

13

GB

General instructions

Read these instructions carefully before
installation and use. Keep this manual for
future reference.

The guarantee is only valid if the
Thermozone units are used in the manner
intended by the manufacturer and in
accordance with the Frico installation and
maintenance instructions.

Application area

The SF air curtain unit is intended for
installation in curved doorways.

SF is installed to the side of the entrance.

Operation

Air is drawn in at the side of the unit and
blown out towards the entrance so that it
shields the door opening and minimizes heat
loss. To achieve the optimum curtain effect
the unit must extend the full height of the
door opening.

The grille for directing exhaust air is

adjustable and is normally angled towards the
curved doorway to achieve the best protection
against incoming cold air.

The airflow can be adjusted by use of the fan

speed selector.

The efficiency of the air curtain(s) depends

on the air temperature, pressure differences
across the doorway and any wind pressure.

NOTE! Negative pressure in the building

considerably reduces the efficiency of the air
curtain. The ventilation should therefore be
balanced!

Installation

The unit is installed as floor standing on
adjustable feet that make it possible to
compensate for possible irregularities in the
floor. The feet are bolted to the floor and
covered by a covering edge. SF is mounted
to the left of the door seen from inside the
building and should also be secured to the
door. SF has a curved design that integrates
neatly with the door. Extension is possible up
to 3900 mm (extension without fans).

Ensure that the service hatch is accessible

and can be fully opened.

See sketches p.2-3.

Electrical installation

Electrical connection may only be carried
out by an authorized electrician, and in
accordance with these instructions and the
applicable regulations.

1. The service hatch is opened by slackening

off the screws in the side of the unit.

2. The unit is connected via one of the cable

glands in the upper or lower side of the
unit.


Different combinations for controlling fan
speed are available. See wiring diagram (p. 6).

Water coil connection

The water coil has copper tubes with
aluminium fins and is suitable for connection
to a closed water heating system. The heating
coil must not be connected to a mains
pressure water system or an open water
system.

The water pipes are connected to the

terminals with DN25 (1"), internal thread on
the inside of the unit. Use a wrench or similar
to hold the air curtain connections to prevent
straining the pipes and subsequent water
leakage during connection to water supply
pipe-work.

The connections to the heating coil must be

equipped with shut off valves to allow problem
free removal. The highest point of the pipes
supplying the unit with water must also be
fitted with a bleed valve. The installation must
be carried out by an authorised installer.

Basic setting fan speed

The fan speed is set using the speed control.

Note that the air flow direction and speed
may need fine adjustment depending on the
loading of the door.

Assembly and operating instructions
