Thermozone Portier

16

The efficiency of the air curtain(s) depends on the
air temperature and pressure differences across the
doorway and any wind forces.
NOTE! Negative pressure differential in buildings
considerably reduces the efficiency of the air
curtain, ventilation should therefore be balanced.

The airflow is set with the airflow selector so that
the air velocity is 3-4 m/s 1 m above the floor.
NOTE! When PS210E09 or PS215E14 is set on
high heat output, the fan speed is automatically
set to high.  A baffle on each side of the doorway
will improve the efficiency of the air curtains.

Trouble shooting
If the fans stop, check the following:
a) Power supply; check fuses, safety cut-out and
time switch (if any) that starts and stops the unit.
b) That the airflow selector is correctly set.  If the
error cannot be fixed, please contact qualified
service technician.

If there is no heat, check the following:
a) Power supply to electric heater; check fuses and
    safety cut-out (if any).
b) Thermostat settings and actual temperature.
c) That the output selector (if any) is set correctly.
d) That the overheat protection has not been
    released. If so, please check description on next
     page.

O v e r h e a t i n g
The Thermozone Portier is equipped with an
overheat protector. If it is released due to
overheating, reset as follows:
a) Disconnect the electric supply.
b) Investigate the problem and repair the fault.
c) Reset is performed as follows: Locate the red
   button which is located inside the air curtain at
   the inner gable to which the fan and the motor
   are attached. It can be seen through the outlet
   grille See fig. G. Press the button with at screw
   driver until a click is heard.
d) Connect the air curtain again.

If the error cannot be fixed, please contact
qualified service technician.

  Safety
Ensure that the area around the intake and
exhaust grille is kept free from objects which could
prevent the air to flow through the unit!  During
operation the surfaces of the unit are hot! The unit
must never be covered fully or partially with
clothes, or similar which can cause risk of fire!

M a i n t e n a n c e
NOTE! Always disconnect the electricity prior to
cleaning or inspection (units with electric heat can
be supplied from more than one connection).  The
fan motors and the other components require no
maintenance other than cleaning, once a year is
recommended. Grille, impeller and elements are
vacuum cleaned or cleaned with a damp cloth.
Open the front panel to reach elements and
i m p e l l e r s .

Earth leakage protection
If the installation is protected by a safety cutout,
which triggers when the appliance is connected, it
may be due to moisture inside the heating
elements. When an appliance containing a
heating element has not been used for a long
period of time and is stored in a damp
environment, moisture can enter the element. This
should not be seen as a fault, but is simply rectified
by connecting the appliance to the mains supply
via a socket without a safety cut-out, so that the
moisture can be vaporised out of the element.  The
drying time can vary from a few hours to a few
days. As a preventive measure the air curtain
should occasionally be run for a short time.

The guarantee is only valid if the Thermozone
Portier units are used in the manner intended by
the manufacturer and in accordance with the
installation and maintenance instructions.
