Type
RSK-nr
Description
HxWxD
[mm]
L
[m]
SIReB
Control system Basic
SIReAC
Control system Competent
SIReAA
Control system Advanced
SIReRTX
673 09 22
External room temperature sensor
70x33x23
SIReUR
673 09 21
Kit for recessed installation
114x70x50
SIReWTA
Clamp-on sensor
SIReCJ4
Joint piece for two pcs. RJ11 (4/4)
SIReCJ6
Joint piece for two pcs. RJ12 (6/6)
SIReCC603
673 09 23
Modular cable RJ12
3
SIReCC605
673 09 24
Modular cable RJ12
5
SIReCC610
673 09 25
Modular cable RJ12
10
SIReCC615
673 09 26
Modular cable RJ12
15
SIReCC403
673 09 27
Modular cable RJ11
30
SIReCC405
673 09 28
Modular cable RJ11
50
SIReCC410
673 09 29
Modular cable RJ11
10
SIReCC415
673 09 30
Modular cable RJ11
15
Regulations alternatives
This aircurtain is supplied with an intelligent
and well designed low voltage control
system SIRe which can be customized for
each unique application and environment.
The control system is pre-installed in the
aircurtain with an integrated control card.
Type
RSK-nr
Description
Flow
Connection
VMO15LF
673 09 47
Modulating valve kit
Low
DN15
VMO15NF
673 09 48
Modulating valve kit
Normal
DN15
VMO20
673 09 49
Modulating valve kit
Normal
DN20
VMO25
673 09 50
Modulating valve kit
Normal
DN25
VMOP15LF
673 09 51
Pressure independent and modulating valv kit
Low
DN15
VMOP15NF
673 09 52
Pressure independent and modulating valve kit
Normal
DN15
VMOP20
673 09 53
Pressure independent and modulating valve kit
Normal
DN20
VMOP25
673 09 54
Pressure independent and modulating valve kit
Normal
DN25
VOS15LF
673 09 35
Valve kit on/off
Low
DN15
VOS15NF
673 09 36
Valve kit on/off
Normal
DN15
VOS20
673 09 37
Valve kit on/off
Normal
DN20
VOS25
673 09 38
Valve kit on/off
Normal
DN25
VOSP15 LF
673 09 43
Pressure independent valve kit
Low
DN15
VOSP15NF
673 09 44
Pressure independent valve kit
Normal
DN15
VOSP20
673 09 45
Pressure independent valve kit
Normal
DN20
VOSP25
673 09 46
Pressure independent valve kit
Normal
DN25
VOT15
Three way valve and actuator on/off
Normal flow
DN15
VOT20
Three way valve and actuator on/off
Normal flow
DN20
VOT25
Three way valve and actuator on/off
Normal flow
DN25
VMT15
Three way valve and modulating actuator
Normal flow
DN15
VMT20
Three way valve and modulating actuator
Normal flow
DN20
VMT25
Three way valve and modulating actuator
Normal flow
DN25
VAT
482 98 30
Adjustment tool for valve kit
Water regulation
SIRe is supplied pre-programmed with quick-
release connections and is very easy to use
and install. There are three different levels
with different functionality to choose from,
Basic, Competent or Advanced.
Accessories
PA3500/4200
13
