IRCF

11

GB

General instructions

Read these instructions carefully before
installation and use. Keep this manual for
future reference. During installation and
maintenance and when replacing the lamp
the heater should always be disconnected
from the power supply.

The element of IRCF is a halogen quartz

lamp that is operating at about 2200 ºC.

The guarantee is only valid if the heater is
installed and used in a way that is described
in this instruction.

Application area

IRCF is especially designed for spot heating
of premises with large air volumes, such as
churches, aircraft hangars, industries and
warehouses.This infrared heater is tested and
approved according to the EMC- and LVD
regulations and is CE compliant.

Normally IRCF is used to give comfort for

people in the area in front of or under the
heater.

With its high efficiency and compact size it

is perfect for many difficult applications.

Mounting

After unpacking make sure that the appliance
is complete and shows no signs of visible
damage.

Make sure that the voltage is the same as

indicated on the rating label.

IRCF must be mounted at least 2,3 m above

the floor.

Normally the heater is mounted at 3 – 6 m

height, for spotheating the appliance should
not be mounted higher than 5 m. The best
comfort is experienced when a person is
heated from two directions.

Enclosed in the package there is a wall

bracket. Make sure that the wall is firm and
that proper screws are used.

Make sure that the appliance is directed

at the surface that shall be heated, for
adjustments se fig. 2.

Fig. 3 shows other mounting alternatives,

chains and S-hooks needed for such
installations are to be purchased separately.

Following important notes must be followed:
-  The heater should always be installed

horizontally and only by using the brackets
provided.

-  The heater must not be located directly

below a wall socket.

-   Make sure that the power supplying cable

does not come in contact with the lamps or
is reached by the thermal heat.

-   The minimum distances according to page

2 must be kept.

-  Do not use the heater directly near a

bathtub, a shower or a swimming pool.

-  The heater must be installed so that a

person standing in a shower can reach
neither the switch nor the heater.

-  The heater must not be installed in areas

where hazardous vapours may be present.

Electrical installation

The electrical installation should be
carried out by a qualified electrician and in
conformity with prevailing regulations. When
fixed an all-pole switch with at least 3 mm
breaking gap should precede the appliance.

If a cable connects the heater it should be of

type H05 RN-F or similar.

N.B: The cable glands must be classified as

the heater.

Safety

-  During installation, cleaning and service

the heater must be disconnected from the
power supply.

-  All users should be made aware of all

aspects of operation and safety mentioned
in this instruction.

-  The appliance is only to be used according

to these instructions.

-

This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety. Children should be supervised
to ensure that they do not play with the
appliance.

Mounting and operating instructions
