IH

7

GB

Replacing the halogen lamp

The heat lamp in IH is of the highest quality
and unless it is subjected to mechanical
strains in the form of vibrations and impact
it will last for a long time. The service life
is dependent on the ambient temperature
and how the heater is installed. When the
heater is installed freely and outdoors the
temperature will be low and the life of the
lamp can be expected to be in the region of
3000 hours.

The lamp must be replaced by an installer

or other skilled person.

-  Disconnect the power supply.
-  Wait until the unit is cold.
1. Remove the covers at both ends (four

screws).

2. Pull the grille to one side.
3. Remove both reflector ends (two screws).
4. Loosen the connections on the terminal

block.

5. Pull the lamp out of the lamp holders.
-  Check that the replacement lamp has the

correct output and voltage.

-  Fit the new lamp. Note do not touch the

lamp with your fingers, wear gloves or the
like.

-  The protective tube must be refitted to the

cables, so that the cables are not damaged
when the grille is fitted.

-  Reassemble the unit again.
See fig. 5.

Maintenance

Note! When using for the first time or when
starting up after a long period of disuse, a
small amount of smoke and a slight odour
may occur temporarily, which is completely
normal.

The power supply to the unit must be

disconnected during all service, repair and
maintenance work.

The unit has no moving parts so the

maintenance requirement is small, but it
must be kept clean and free from dust and
dirt. If the reflector is not clean the thermal
radiation from the unit will decrease and the
heater will become hotter. A large amount of

dirt can cause overheating.

The surface of the reflector is sensitive and

must be cleaned with care. If the reflector
is dirty it must be cleaned or replaced by a
specialist.

Safety

•  During operation the surfaces of the unit

are hot!

•  The unit must not be fully or partially

covered with inflammable materials, as
overheating can result in a fire risk!

•  This product is not designed to be used by

children or persons with reduced physical
or mental ability or a lack of experience
and knowledge, unless instruction
regarding the product's use has been
given by a person with responsibility for
their safety or that this person supervises
operation. Children must be kept under
supervision to ensure they do not play
with the product.

•  The heater is equipped with a protective

grille to prevent contact or to prevent
large objects from touching the hot lamp.
The unit must not be used without this
protective grille.

•  Ensure that there are no inflammable

materials gathered on or close to the
heater.

•  The free space to the inflammable

material in the direction of radiation
must be at least 1 meter.

• Do not place the heater directly under the

electrical socket.

• The cable and plug must not be placed

inside the hot radiant area.

• Do not use timer that switches the heater

on automatically since a fire risk exists
if the heater is covered or positioned
incorrectly.
