Type
RSK-nr
Description
HxWxD
[mm]
L
[m]
SIReB
Control system Basic
SIReAC
Control system Competent
SIReAA
Control system Advanced
SIReRTX
673 09 22
External room temperature sensor
70x33x23
SIReUR*
673 09 21
Kit for recessed installation
114x70x50
SIReWTA
Clamp-on sensor
SIReCJ4
Joint piece for two pcs. RJ11 (4p/4c)
SIReCJ6
Joint piece for two pcs. RJ11 (6p/6c)
SIReCC603
673 09 23
Modular cable RJ11 (6p/6c)
3
SIReCC605
673 09 24
Modular cable RJ11 (6p/6c)
5
SIReCC610
673 09 25
Modular cable RJ11 (6p/6c)
10
SIReCC615
673 09 26
Modular cable RJ11 (6p/6c)
15
SIReCC403
673 09 27
Modular cable RJ11 (4p/4c)
3
SIReCC405
673 09 28
Modular cable RJ11 (4p/4c)
5
SIReCC410
673 09 29
Modular cable RJ11 (4p/4c)
10
SIReCC415
673 09 30
Modular cable RJ11 (4p/4c)
15
Regulations alternatives
This aircurtain is supplied with an intelligent
and well designed low voltage control
system SIRe which can be customized for
each unique application and environment.
The control system is pre-installed in the
aircurtain with an integrated control card.
Water regulation
SIRe is supplied pre-programmed with quick-
release connections and is very easy to use
and install. There are three different levels
with different functionality to choose from,
Basic, Competent or Advanced.
Type
Description
Voltage
[V]
Connection
VOS15LF
Valve kit on/off
230 V
DN15
VOS15NF
Valve kit on/off
230 V
DN15
VOS20
Valve kit on/off
230 V
DN20
VOS25
Valve kit on/off
230 V
DN25
VOSP15LF
Pressure independent valve kit
230 V
DN15
VOSP15NF
Pressure independent valve kit
230 V
DN15
VOSP20
Pressure independent valve kit
230 V
DN20
VOSP25
Pressure independent valve kit
230 V
DN25
VMO15LF
Modulating valve kit
24 V
DN15
VMO15NF
Modulating valve kit
24 V
DN15
VMO20
Modulating valve kit
24 V
DN20
VMO25
Modulating valve kit
24 V
DN25
VMOP15LF
Pressure independent and modulating valve kit
24 V
DN15
VMOP15NF
Pressure independent and modulating valve kit
24 V
DN15
VMOP20
Pressure independent and modulating valve kit
24 V
DN20
VMOP25
Pressure independent and modulating valve kit
24 V
DN25
VOT15
Three way valve and actuator on/off
230 V
DN15
VOT20
Three way valve and actuator on/off
230 V
DN20
VOT25
Three way valve and actuator on/off
230 V
DN25
VMT15
Three way valve and modulating actuator
24 V
DN15
VMT20
Three way valve and modulating actuator
24 V
DN20
VMT25
Three way valve and modulating actuator
24 V
DN25
VAT
Adjustment tool for valve kit VOS, VOSP, VMO, VMOP
AR3500
5
