1. GENERAL FEATURES

Remove the appliance from the packaging, turn upside down and rest on the polystyrene.
Check that neither the appliance nor the power cable has been damaged in any way during
transportation.
Do not operate the appliance if damaged

2. FITTING THE FEET

Remove the feet and the castors from the polystyrene packing.
Fit the castors to the spindles on the feet and push firmly until they click into position (fig. 1).
Pull each castor to check that it is fitted correctly.
In certain models, the castors are already mounted on the feet.
Using the threaded u-bolt and wing nuts, fit the feet  to the bottom of the radiator between the
last two elements as shown in figures 2, 3 and 4.
Depending on the type supplied, type A or type B, mount the feet as shown in figure 5 or 6.

Models with “Easy wheel” sytem

Turn the radiator upside-down on a rug or a soft surface in order to prevent damaging the
paint finish. Fully unfold the castors by turning them outwards (Fig.7).
Turn the radiator back to its upright position.

IMPORTANT

When in use, the radiator should always be kept vertical (wheels at the bottom, controls at the

top). Any other position could be dangerous!

3. ELECTRICAL CONNECTION

-

Before plugging the radiator into the mains, check that the voltage of your mains electricity
supply corresponds to the value V indicated on the appliance and that the socket and
power line are appropriately dimensioned.

-

CONNECT THE RADIATOR TO EFFICIENTLY EARTHED SOCKETS ONLY

-

This appliance complies with EEC Directive 89/336 and D.M. 476/92, relating to electro-
magnetic compatibility.

4. INSTRUCTIONS FOR USE
Switching on

Plug into the mains socket. Turn the thermostat to maximum. Switch the radiator on using the
switch/switches following the procedures given in points a) - b).

a) Models with single switch (1 power level):

-

button in position  «I» = Total power on (indicator light on);

-

button in position «O» = (indicator light off)

b) Models with double switch (3 power levels)

-

button in position «

l

» = minimum power (indicator light on);

-

button in position  «

ll

» = intermediate power (indicator light on);

-

both buttons in position «

l

» «

ll

» = maximum power (indicator lights on)

To turn appliance off, switch off both switches or remove plug from wall socket.

Adjusting the thermostat

When the room has reached the required temperature, turn the thermostat slowly anticlockwise
until the indicator light goes out (or until you hear a "click") and no further. The set temperature
will then be regulated automatically and kept constant by the thermostat.

Frost protection function

With the thermostat in position     and the switches pressed, the appliance maintains the room
at a temperature of about 5˚C, preventing freezing with minimum energy consumption.
