Black Shark Goblin X4 - Инструкция по эксплуатации

Three-mode gaming headset BS-X4

USER MANUAL

Product features

1. Enjoy variety of scenarios and devices with three different connection

including normal wireless mode,wireless low latency mode(with dongle)

and 3.5mm wired mode.

2. Support game, video, live different effect to satisfy colorful entertainments

3. Low latency with dongle(delay＜40ms) and high compatiblity,support

PC, Phone, PS4, PS5, Xbox one.

4.Cool RGB LED light.

5.Customized high quality sound unit to provide excellent sound

performance.

6.Detachable bendable microphone has accurate pickup and easy to

storage.

7.Reliable copper extendable headband,and skin-friendly soft earmuffs

supply you a confortable experience.

Product specification

The second connection: Bluetooth

Description of buttons function

The third connection: 3.5mm wired connection

Cautions

Connection
1. Press and hold the power button of the headsets for 3s, you can hear
a voice prompt““Power on”. When the blue light is on, then power on.
 Then the headset enter the paring mode automatically for 3s, the blue
indicator flashes and you can hear a voice promt”Pairing”.
2. Open your device bluetooth, select the the paring name “BS-X4”to
connect. If the blue indicator is always on, it means connected. Once the
headset is paired, it will connect the last device automatically.
3. Or you can long press the power button to the pairing mode for 5s
when the headset is power off. Then operate the connecting steps as above.
Note: Boot failed, please try again after charging.

Disconnecction
Close the headset bluetooth, then the connection is broken.

1. Insert the 3.5mm cable and then start to use it, no matter the headset
battery out of power.
2. In wired mode, all buttons are disabled except for adjusting the volume+/-.
Only unplug the cable then start the bluetooth connection and function.

1.The headset is compatible with Microsoft Windows 7/8/10, Apple Mac
OS systems,and can be used on PS4.
2.If the headset is used on an unlisted operating system or device, it may
not work properly.
Please contact after-sales service for solution.
3.If there is no sound in the microphone or headset during use, it may
be caused by driver compatibility problems or improper use. Please
contact after-sales service for solutions.
4.If the headset is damaged during use, for example, the cable is broken,
please stop using it and contact after-sales service for solutions.
5.If the headset does not respond for a long time, please use a paper
clip or other sharp objects to press the result button for 3s, and the
headset can be powered off automatically.
NOTE: This device contains licence-exempt transmitter(s)/receiver(s) that
comply with Innovation, Science and Economic

Development Canada’s licence-exempt RSS(s). Operation is subject to
the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that
may cause undesired operation of the device.L’émetteur/récepteur
exempt de licence contenu dans le présent appareil est conforme aux
CNR d’Innovation, Sciences et Développement économique Canada
applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes :
(1) L' appareil ne doit pas produire de brouillage;
(2) L' appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d' en compromettre le fonctionnement.

NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiateradio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged

to try to correct the

interferenceby one or more of the following measures:

- Reorient or

relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help

Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
This device complies with Part15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation

The red indicator is on when charging.  Green indicator is on when fully
charged.

Reset hole

Power indicator

If the headset does not respond for a long time, please use a paper clip
or other sharp objects to press the reset button for 3s, and the headset
can be powered off automatically.

Mode switch (sound EQ effect)

Short press once ”EQ” button to switch modes. There will be a voice
prompt ” Gaming mode”/ ” Music mode”/” Live mode”. The EQ
effect will be the same as before automatically when power on.

RGB light switch( L & R shape)

Short press to open/close the RGB LED.

Wired connection mode

1. Insert the 3.5mm cable to the AUX port of headset and the other side
to your device.
2. In wired mode, all buttons are disabled except for adjusting the volume+/-.

Microphone on/off

Plug the microphone on the headset firstly. Then Press once the
microphone button to turn the microphone on/off.

Connect automatically

1. When the headset disconnect with the USB dongle, headset will connect
the last device automatically and LED flashes for 3 mins. The EQ setting
will be the same as before.
2. Such as the headset is connected with the device 1 computer(with dongle)
and then connected the device 2 phone, if you want to connect the device1,
close the device 2 phone bluetooth and then unplug and plug the USB
dongle again.

Headset Charging

1. Please charge when you use the BS-X4 headset firstly.

2

. If the power of the headset is less than 20%,you will hear”Low Power”

once in every 5mins and the RED indicator will flash once in every 5s.
3. When you charge with the Type C cable, headset is power off and
then the indicator will grow red. When the headset is fully charged, the
indicator grow green.

Headset Connection and Disconnection
Different with normal wireless headset, BS-X4 supports three connection
modes.

Connection:
1. Insert the USB dongle into the USB port of your device, the blue
indicator of USB dongle flashes.
2. Press and hold the power button of the headsets for 3s,you can
hear “Power on ” and see the headset power light on. It means the
headset is power on.
3. If you are the first time using the headset, you will hear”Paring”
and see the blue indicator flashes. When the headset green light is
always on, it means connected.
Note: The headset will connect the last device after power on
automatically. Boot failed, please try again after charging.

Disconnection
Remove the USB dongle from your device, then the connection is broken.

The first connection: USB Dongle (Low latency)

Thanks for you choosing BLACK SHARK BS-X4  .

Ensure you have a great experience, please use it under the operation of

user manual.

Frequency Range

20~20KHz

Speaker Diameter

50mm

Speaker Sensitivity

111dB±3dB(I/P Level: 1mW, at 1KHz)

Speaker Impedance

32 Ω±15%

Speaker Input

10mW（F=1KHz，THD=5%）

Speaker Maximum Power      30mW

Microphone Diameter            Ø9.7x4.5mm

Microphone Sensitivity          -38dB±3dB

RGB LED

Power on/Power off

Press and hold the power button for 3s, then power on/off.

Volume +/-

Slide roller tuning to adjust the volume up/down.

Indicator

Reset hole

Model: BS-X4
Product Description: Three-mode gaming headset

Manufacturer: Room 1501, Building 1, Chongwen Park, Nanshan
Zhiyuan, No. 3370, Liuxian Avenue, Fuguang Community, Taoyuan
Street, Nanshan District, Shenzhen, Guangdong, China
Visit

global.blackshark.com

 for more information

FCC ID：2A2JO-BSX
IC ID：27499-BSX
MIC：210-178736
