Edifier W820NB Plus - Инструкция по эксплуатации

EN  1. Power ON/OFF

2. Pairing

3. Reset

4. Charging

5. Connecting to PC as wired headphones

6. Controls

For more information, please visit our website:

www.edifier.com

@Edifier_Global

@Edifier_Global

@Edifierglobal

Model: EDF200118
Edif er International Limited
P.O. Box 6264
General Post Off ce
Hong Kong

www.edif er.com
    2022 Edif er International Limited. All rights reserved.
Printed in China

NOTICE:
For the need of technical improvement and system upgrade,information
contained herein may be subject to change from time to time without prior
notice.
Products of EDIFIER will be customized for different applications.
Pictures and illustrations shown on this manual may be slightly different
from actual product.
If any difference is found, the actual product prevails.

Wireless Noise Cancellation Over-Ear Headphones

W 8 2 0 N B   P l u s

Manual

3s

Indicator

Indicator

Indicator

Note:

Under wireless mode: 1. If there is no Bluetooth connection for 5 minutes after
power on, the headphones will turn off automatically. 2. If there is no Bluetooth
connection when the noise cancellation is on, the headphones will turn off
automatically after 4 hours.

1. Power ON: press and hold the "     " key for
    about 3s when powered OFF until the LED
    blinks blue.
2. Power OFF: press and hold the "     " key for
    about 3s when powered ON until the LED
    blinks red.

Pairing for new device

1. Press and hold the "     " key for about 6s when powered off to skip the latest
    connected device and pair the new Bluetooth device. Blue and green LED
    will blink alternately and rapidly.
2. Select "EDIFIER W820NB Plus" in your device setting to connect. Blue LED
    will blink twice after connected.

Pairing for the f rst time

1. Press and hold the "     " key for about 3s
    when powered off. Blue and green LED
    will blink alternately and rapidly.
2. Select "EDIFIER W820NB Plus" in your device
    setting to connect. Blue LED  will blink twice
    after connected.

Note:

For subsequent use, the headphones will automatically connect to the device
used last time.

Simultaneously press and hold the "     " "     "
keys for about 5s when powered on to clear
pairing records. Blue LED will blink 6 times
rapidly when successful.

5s

1. Connect the small end of the included USB cable to
    the USB-C port of the headphones and connect the
    other end to a USB-A power supply or wall charger
    (not included).
2. Orange LED is steady lit when charging and off when
    fully charged.

Note:

Please do not charge the headphones when there is sweat or other liquids
inside the charging port, which may damage the headphones.

Input: 5V      1A

1. Connect the small end of the included USB cable to the USB-C port of the
    headphones and connect the other end to the USB-A port of the PC. You
    can listen to music,  talk and charge the headphones after the connection
    is successful.
2. Orange LED is steady lit when charging and green LED is steady lit when
    fully charged.

Note:

It is recommended to use the included USB cable, and other cables may have
compatibility issues that prevent them from working properly.

x2

3s

x1

x2

x1

x1

6s

x1

x2

x1

x1

x1

ANC

Note:

1.       : Press and hold.
2. Default sound control: noise cancellation & ambient sound.
3. Images are for illustrative purposes only and may differ from the actual
    product.
4. Download Edif er Connect App for more customizable control settings.

i

i

i

i

i

i
