en

Instructions for use

14

JET 4000 / JET 5000 / JET 6000

Inox stainless steel

Units  marked  with  the  designation  "INOX"  are

supplied in stainless steel. The structure and func-

tion are unaffected by this.

Designated use

The  garden  pump  is  intended  for  private  use  in

house  and  garden.  It  must  only  be  used  in  the

framework of the deployment limitations in accor-

dance with the technical data.
The garden pump is suitable for:

Watering and irrigating
Re-pumping and pumping out of vessels (e.g.

swimming pools)
Water  extraction  from  streams,  rainwater

butts and cisterns.

The  garden  pump  is  is  suited  exclusively  for  the

conveying of the following fluids:

Clear water, rainwater
water  containing  chlorine  (e.g.  swimming

pools)

Any other use shall be regarded as misuse.

Possible misuse

The garden pump must not be used continuously.

They are not suitable for conveying:

Drinking water
Salt water
Waste water
Foodstuffs
aggressive media, chemicals
corrosive,  flammable,  explosive  or  fuming

fluids
Fluids that are hotter than 35 °C
water containing sand and abrasive fluids.

SAFETY INSTRUCTIONS

CAUTION!
Danger of injury!

Only use the machine and the extension

cable if it is in perfect technical condition!

Damaged units must not be used.
Safety  and  protective  devices  must  not

be deactivated!

Children, or people who are not familiar with

the operating instructions, are not allowed to

use the machine.

Never lift, transport or suspend the unit using

the connection cable.
Unilateral modifications or conversions of the

unit are prohibited.

Electrical safety

CAUTION!
Danger  when  touching  voltage  con-

ducting parts!

Disconnect the plug from the mains if the

extension cable is damaged or severed!

We  recommend  connecting  a  RCD  (re-

sidual current operated device) having a

nominal residual current of < 30 mA.

The house mains voltage must agree with the

details  quoted  in  the  technical  data,  do  not

use any other supply voltage.
The  unit  must  only  be  operated  with  an

electrical installation in accordance with DIN/

VDE 0100, Part 737, 738 and 702 (swimming

pools). Protection must be provided by a 10 A

line protection switch and a RCCD (residual

current operated device) having a nominal re-

sidual current of 10/30 mA.
Use  only  extension  cables  that  are  suitable

for use outdoors - minimum cross-section 1.5

mm

2

. Cable drums should always be unrolled

completely.
Damaged or brittle extension cables must not

be used.

➯

Check  the  condition  of  your  extension

cable  each  time  you  start  to  use  the

equipment.

ASSEMBLY

Setting up the equipment

1. Prepare a flat and solid location.
2. Erect  the  unit  horizontally  and  safe  from  the

risk of flooding.

➯

The unit must be protected from the rain

and direct water jets.

Mounting the pressure line

1. Screw the connecting nipple

(Fig. B -15)

 with

the round seal ring

(Fig. B -16)

 into the pump

outlet

(Fig. A -3)

.

2. Screw the elbow nipple

(Fig. B -13)

 with seal

ring

(Fig.  B  -14)

  onto  the  connecting  nipple

(Fig.  B  -15)

  and  turn  the  elbow  nipple  in  the

desired direction.
